XYCOM XVME-531模拟输出模块

XYCOM XVME-531模拟输出模块

1.产 品 资 料 介 绍：

1. 采用 6U VME 总线架构，单插槽安装。
2. 提供 16 路独立模拟输出通道。
3. 12 位 D/A 转换精度，输出稳定可靠。
4. 支持 0–10V、±5V、±10V 多档电压输出。
5. /2 版本支持 4–20mA 标准工业电流输出。
6. /2 版本每通道具备 500V 光电隔离。
7. /1 版本为非隔离，适合近距离低干扰环境。
8. 支持单通道独立更新与多通道同步更新。
9. 电压输出响应快，稳定时间短。
10. 板载校准电路，支持增益与偏置调节。
11. 占用 1KB VME 短 I/O 地址，基址可跳线设置。
12. 采用前置 50 针连接器，接线方便。
13. 由 VME 总线 +5V 供电，满足工业长期运行。
14. 工作温度 0–65℃，适应工控现场环境。
15. 多用于过程控制、阀门调节、仪表驱动、DCS 系统。

XYCOM XVME-531模拟输出模块  英文资料：

XVME-531 is a 6U VME bus 16 channel 12 bit analog output module launched by Xycom, available in isolated and non isolated versions, suitable for industrial multi loop control.

Adopting a 6U VME bus architecture and single slot installation.

Provide 16 independent analog output channels.

12 bit D/A conversion accuracy, stable and reliable output.

Supports multiple voltage outputs ranging from 0-10V, ± 5V, and ± 10V.

/Version 2 supports 4-20mA standard industrial current output.

/Version 2 has 500V optoelectronic isolation per channel.

/Version 1 is non isolated and suitable for close range low interference environments.

Support single channel independent updates and multi-channel synchronous updates.

Fast voltage output response and short stabilization time.

Onboard calibration circuit, supporting gain and bias adjustment.

Occupy 1KB of VME short I/O address, the base address can be set by jumper.

Adopting a front 50 pin connector for easy wiring.

Powered by VME bus+5V to meet long-term industrial operation.

Working temperature range of 0-65 ℃, suitable for industrial control site environment.

Commonly used for process control, valve regulation, instrument drive, and DCS systems.

XVME-531 has become a commonly used module for analog control in VME systems due to its high-density channels, multi range output, and high reliability.

XYCOM XVME-531模拟输出模块  产品展示
