XYCOM XVME-566模拟输入卡

1.产 品 资 料 介 绍：

XYCOM XVME-566 模拟输入卡产品特点

1. 支持32 路单端 / 16 路差分模拟输入，可按现场抗干扰需求灵活切换。
2. 采用12 位 A/D 转换，单通道最高100kHz采样率，满足高速动态信号采集。
3. 内置64KB 双口 RAM，可存储超 32000 个采样点，缓解高速采集时 VME 总线带宽压力。
4. 配备256 字节序列 RAM，可编程自定义通道采样顺序，适配复杂采集流程。
5. 单通道12 级可编程增益，通过增益 RAM 独立配置，适配微弱与强幅传感器信号。
6. 支持板载 / 外部 / 软件三种触发方式，搭配可编程采样时钟，灵活控制采集节奏。
7. 兼容 VMEbus 标准中断与可编程中断定时器，便于系统实时响应采集事件。
8. 采用6U 双槽 VME 板卡结构，符合 VMEbus 机械规范，安装与扩展便捷。
9. 工业级宽温设计，适配 - 40℃至 + 85℃恶劣工业环境，运行稳定可靠。
10. 内置信号调理电路，可直接接入工业传感器，减少外围电路设计与调试成本。
11. 支持 VMEbus 标准供电，低功耗设计，适配高密度机架式部署。
12. 兼容主流 VMEbus 控制系统与 EPICS 等工业软件，系统集成兼容性强。
13. 出厂校准参数固化，保障长期使用的采集精度稳定性。
14. 适用于高速数据采集、设备状态监测、自动化测试、工业过程控制等场景。

XYCOM XVME-566模拟输入卡   英文资料：

XYCOM XVME-566 Analog Input Card Product Features

XYCOM XVME-566 is a high-performance industrial analog input card designed for the VMEbus bus, featuring high-speed data acquisition, large capacity cache, and flexible channel configuration, suitable for industrial automation, high-speed data acquisition, and process control scenarios.

Supports 32 single ended/16 differential analog inputs, which can be flexibly switched according to on-site anti-interference requirements.

Adopting 12 bit A/D conversion and a maximum single channel sampling rate of 100kHz, it meets the requirements of high-speed dynamic signal acquisition.

Built in 64KB dual port RAM, capable of storing over 32000 sampling points, relieving the bandwidth pressure of VME bus during high-speed acquisition.

Equipped with 256 byte sequential RAM, programmable custom channel sampling order, suitable for complex acquisition processes.

Single channel 12 level programmable gain, independently configured through gain RAM, suitable for weak and strong amplitude sensor signals.

Supports three triggering modes: onboard/external/software, paired with a programmable sampling clock to flexibly control the acquisition rhythm.

Compatible with VMEbus standard interrupts and programmable interrupt timers, facilitating real-time system response to collection events.

Adopting a 6U dual slot VME board structure, it complies with VMEbus mechanical specifications and is easy to install and expand.

Industrial grade wide temperature design, suitable for harsh industrial environments ranging from -40 ℃ to+85 ℃, stable and reliable operation.

Built in signal conditioning circuit, can be directly connected to industrial sensors, reducing the cost of peripheral circuit design and debugging.

Supports VMEbus standard power supply, low-power design, and is suitable for high-density rack mounted deployment.

Compatible with mainstream VMEbus control systems and industrial software such as EPICS, with strong system integration compatibility.

Factory calibration parameters are solidified to ensure the stability of collection accuracy for long-term use.

Suitable for scenarios such as high-speed data acquisition, equipment status monitoring, automated testing, and industrial process control.
