Xycom XVME-601 处理器模块

1.产 品 资 料 介 绍：

Xycom XVME-601 处理器模块产品特点

1. 采用Motorola 68000/68010 处理器，主频 10MHz，满足工业实时控制与数据处理需求。
2. 标准VMEbus A24/A16:D16/D08 (EO) 总线主设备，兼容主流 VME 控制系统，无缝集成。
3. 板载512KB 本地 DRAM，支持128KB EPROM 扩展，CPU 零等待周期访问本地存储。
4. 集成68681 DUART，提供2 路 RS-232 串口与16 位可编程定时器，满足外设通信与定时控制。
5. 内置完整 VME 总线管理功能：SYSCLK、SYSRESET、单级仲裁器、总线定时器、IACK 菊花链驱动。
6. 支持7 级硬件中断（IRQ0-IRQ7），可灵活响应外部事件，保障系统实时性。
7. 前面板3 个状态 LED，实时显示诊断结果、CPU 运行 / 停机状态，便于现场调试。
8. 工业级宽温设计（-40℃~+85℃），适配恶劣工业环境，长期稳定运行。
9. 单高 6U VME 板卡结构，尺寸紧凑，支持高密度机架部署，安装维护便捷。
10. 内置硬件看门狗，异常时自动复位，提升系统可靠性与故障恢复能力。
11. 支持本地监控程序，提供基础诊断、内存读写与启动配置，简化开发与调试。
12. 兼容 VMEbus 标准供电，低功耗设计，适合长期连续运行的工业场景。
13. 提供完整开发工具链与文档支持，便于二次开发与系统定制。
14. 适用于工业自动化、过程控制、数据采集、测试测量、军事电子等领域。

Xycom XVME-601 处理器模块   英文资料：

Xycom XVME-601 processor module product features

Xycom XVME-601 is a single high VMEbus industrial processor module equipped with Motorola 68000/68010 CPUs, designed specifically for industrial real-time control, data acquisition, and embedded systems, balancing compatibility, reliability, and real-time performance.

Adopting Motorola 68000/68010 processors with a main frequency of 10MHz, it meets the real-time control and data processing needs of industry.

Standard VMEbus A24/A16: D16/D08 (EO) bus master device, compatible with mainstream VME control systems, seamlessly integrated.

On board 512KB local DRAM, supports 128KB EPROM expansion, and CPU has zero waiting period to access local storage.

Integrated 68681 DUART, providing 2 RS-232 serial ports and 16 bit programmable timers to meet peripheral communication and timing control needs.

Built in complete VME bus management functions: SYSCLK, SYSRESET, single-stage arbiter, bus timer, IACK daisy chain driver.

Supports level 7 hardware interrupts (IRQ0-IRQ7), which can flexibly respond to external events and ensure system real-time performance.

There are three status LEDs on the front panel, which display diagnostic results and CPU running/shutdown status in real-time for easy on-site debugging.

Industrial grade wide temperature design (-40 ℃~+85 ℃), suitable for harsh industrial environments, long-term stable operation.

Single height 6U VME board structure, compact size, supports high-density rack deployment, easy installation and maintenance.

Built in hardware watchdog that automatically resets in case of abnormalities, enhancing system reliability and fault recovery capabilities.

Support local monitoring programs, provide basic diagnostics, memory read/write, and boot configuration, simplify development and debugging.

Compatible with VMEbus standard power supply, low-power design, suitable for industrial scenarios with long-term continuous operation.

Provide a complete development toolchain and documentation support for secondary development and system customization.

Suitable for industrial automation, process control, data acquisition, testing and measurement, military electronics and other fields.

Xycom XVME-601 处理器模块   产品展示
