Xycom XVME-655 CPU单元处理器卡

1.产 品 资 料 介 绍：

Xycom XVME-655 CPU 单元处理器卡产品特点

1. 搭载Intel Pentium 处理器，主频覆盖75/100/133/166/200/233MHz（含 MMX 版本），满足高性能实时计算需求。
2. 兼容IBM PC/AT 标准，可直接运行 Windows、DOS 等 PC 生态软件，开发与迁移成本低。
3. 板载64MB SDRAM，支持256KB/512KB 二级高速缓存（COAST），搭配 CPU 内置 16KB 一级缓存，数据访问效率高。
4. 集成32 位 PCI 本地总线，内置PCI Super VGA 图形控制器，支持本地显示输出。
5. 提供2 路 16550 兼容 RS-232 串口、1 路 EPP/ECP 兼容并口，满足基础外设通信。
6. 支持VMEbus A32/A24/A16:D64/D32/D16总线主 / 从模式，兼容 IEEE 1014-1987 Rev. C.1 标准。
7. 具备完整 VME 总线管理：SYSCLK/SYSRESET 驱动、多级仲裁器、7 级中断（I1-I7），系统实时性强。
8. 采用双高双宽 6U VME 板卡结构（233.35mm×160mm），机械强度高，适配工业机架。
9. 工业级宽温设计（-40℃~+85℃），抗电磁干扰，支持冗余配置，恶劣环境稳定运行。
10. 支持XVME-978 系列扩展模块（无需额外 VME 槽位），可扩展10/100Mbps 以太网、Fast & Wide SCSI接口。
11. 兼容XVME-976 扩展板，支持PMC、PC/104、ISA/PCI卡扩展，I/O 配置灵活。
12. 内置硬件看门狗与 Phoenix BIOS，支持系统自检、异常复位与启动配置，可靠性高。
13. 前面板集成状态 LED，实时显示 CPU 运行、总线活动与故障状态，便于现场调试。
14. 支持 VME 标准供电，功耗控制合理，适配高密度机架部署与长期连续运行。
15. 适用于工业自动化、DCS/PLC 控制、数据采集、测试测量、军事电子等高性能嵌入式场景。

Xycom XVME-601 处理器模块   英文资料：

Xycom XVME-655 CPU Unit Processor Card Product Features

Xycom XVME-655 is a high-performance Pentium architecture industrial processor card based on VMEbus, integrating PC/AT compatibility and VME bus reliability. It features high clock speed, rich scalability, and industrial grade stability, and is suitable for complex industrial control and data processing scenarios.

Equipped with Intel Pentium processor, the clock speed covers 75/100/133/166/200/233MHz (including MMX version), meeting high-performance real-time computing requirements.

Compatible with IBM PC/AT standards, it can directly run PC ecosystem software such as Windows and DOS, with low development and migration costs.

Onboard 64MB SDRAM, supports 256KB/512KB level 2 cache (COAST), and is paired with a CPU built-in 16KB level 1 cache for high data access efficiency.

Integrated 32-bit PCI local bus, built-in PCI Super VGA graphics controller, supports local display output.

Provide 2 channels of 16550 compatible RS-232 serial ports and 1 channel of EPP/ECP compatible parallel port to meet basic peripheral communication needs.

Supports VMEbus A32/A24/A16: D64/D32/D16 bus master/slave mode, compatible with IEEE 1014-1987 Rev.

Equipped with complete VME bus management: SYSCLK/SYSRESET driver, multi-level arbiter, 7-level interrupts (I1-I7), the system has strong real-time performance.

Adopting a dual height and dual width 6U VME board structure (233.35mm × 160mm), it has high mechanical strength and is suitable for industrial racks.

Industrial grade wide temperature design (-40 ℃~+85 ℃), anti electromagnetic interference, supports redundant configuration, stable operation in harsh environments.

Supports XVME-978 series expansion modules (without additional VME slots), capable of expanding 10/100Mbps Ethernet and Fast&Wide SCSI interfaces.

Compatible with XVME-976 expansion board, supporting PMC, PC/104, ISA/PCI card expansion, and flexible I/O configuration.

Built in hardware watchdog and Phoenix BIOS, supporting system self-test, abnormal reset, and boot configuration, with high reliability.

The front panel integrates a status LED, which displays real-time CPU operation, bus activity, and fault status for easy on-site debugging.

Support VME standard power supply, reasonable power consumption control, suitable for high-density rack deployment and long-term continuous operation.

Suitable for high-performance embedded scenarios such as industrial automation, DCS/PLC control, data acquisition, testing and measurement, military electronics, etc.

Xycom XVME-655 CPU单元处理器卡   产品展示
