Xycom XVME-660处理器模块

1.产 品 资 料 介 绍：

Xycom XVME-660 处理器模块产品特点

1. 搭载 **Intel Pentium III（600/700MHz）或 Celeron（566MHz）** 处理器，支持 MMX 指令集，满足高性能实时计算与多任务处理。
2. 兼容IBM PC/AT 标准，可直接运行 Windows、DOS、VRTX、UNIX 等 PC / 实时操作系统，软件生态成熟。
3. 板载64MB SDRAM，部分版本支持扩展至128MB，搭配 CPU 内置缓存，保障复杂程序流畅运行。
4. 集成PCI EIDE、Ultra SCSI、10/100Mbps 以太网控制器，提供高速存储与网络通信能力。
5. 配备2 路高速 RS-232 串口、1 路 EPP/ECP 并口、PS/2 键鼠接口、USB 通用端口，基础外设连接全面。
6. 支持VME64x 协议，兼容 VMEbus A32/A24/A16:D64/D32/D16 主 / 从模式，总线数据传输高效。
7. 内置1 个 PMC 扩展槽、1 个 IP（Industry Pack）扩展槽，无需额外载板即可扩展高速 I/O 与通信模块。
8. 采用双槽 6U VME 板卡结构，机械强度高，适配标准工业 VME 机架安装。
9. 工业级宽温设计（-40℃~+85℃），抗电磁干扰，支持冗余电源输入，恶劣环境稳定运行。
10. 集成硬件看门狗、实时时钟（RTC，带电池备份），保障系统异常自动复位与时间同步。
11. 前面板集成状态 LED，实时显示 CPU 运行、总线活动与故障状态，便于现场调试与诊断。
12. 兼容 XVME 系列扩展模块（如 XVME-976/978），可进一步扩展 PCI/PC/104/PMC 等接口，I/O 配置灵活。
13. 支持 VME 标准供电（+5V DC），功耗控制合理，适配高密度机架部署与长期连续运行。
14. 适用于工业自动化、DCS/PLC 控制、数据采集、测试测量、航空航天、军事电子等高性能嵌入式场景。

Xycom XVME-660处理器模块   英文资料：

Product Features of Xycom XVME-660 Processor Module

Xycom XVME-660 is a dual slot 6U VMEbus high-performance PC compatible processor module, equipped with Pentium III/Celeron processors, integrating PC ecology and VME bus reliability, focusing on high performance, rich scalability, and industrial grade stability, suitable for complex industrial control, data processing, and real-time embedded scenarios.

Equipped with * * Intel Pentium III (600/700MHz) or Celeron (566MHz) * * processors, supporting MMX instruction set, meeting high-performance real-time computing and multitasking requirements.

Compatible with IBM PC/AT standards, it can directly run PC/real-time operating systems such as Windows, DOS, VRTX, UNIX, etc., with a mature software ecosystem.

Onboard 64MB SDRAM, some versions support expansion up to 128MB, paired with CPU built-in cache to ensure smooth running of complex programs.

Integrated PCI EIDE, Ultra SCSI, 10/100Mbps Ethernet controller, providing high-speed storage and network communication capabilities.

Equipped with 2 high-speed RS-232 serial ports, 1 EPP/ECP parallel port, PS/2 keyboard and mouse interface, USB universal port, and comprehensive basic peripheral connectivity.

Supports VME64x protocol, compatible with VMEbus A32/A24/A16: D64/D32/D16 master/slave mode, efficient bus data transmission.

Built in 1 PMC expansion slot and 1 IP (Industry Pack) expansion slot, high-speed I/O and communication modules can be expanded without the need for an additional carrier board.

Adopting a dual slot 6U VME board structure, it has high mechanical strength and is compatible with standard industrial VME rack installation.

Industrial grade wide temperature design (-40 ℃~+85 ℃), resistant to electromagnetic interference, supports redundant power input, and operates stably in harsh environments.

Integrated hardware watchdog and real-time clock (RTC, with battery backup) to ensure automatic reset and time synchronization in case of system abnormalities.

The front panel integrates a status LED, which displays real-time CPU operation, bus activity, and fault status for easy on-site debugging and diagnosis.

Compatible with XVME series expansion modules (such as XVME-976/978), it can further expand PCI/PC/104/PMC and other interfaces, with flexible I/O configuration.

Supports VME standard power supply (+5V DC), with reasonable power consumption control, suitable for high-density rack deployment and long-term continuous operation.

Suitable for high-performance embedded scenarios such as industrial automation, DCS/PLC control, data acquisition, testing and measurement, aerospace, military electronics, etc.

Xycom XVME-660处理器模块   产品展示
