XYCOM XVME-661处理器模块

1.产 品 资 料 介 绍：

Xycom XVME-661 处理器模块产品特点

1. 搭载低功耗 Intel Pentium III 700MHz 处理器，内置256KB 全速片上二级缓存，兼顾高性能与低功耗。
2. 支持最大 256MB SDRAM（单条 144-pin SODIMM），满足复杂程序与多任务运行需求。
3. 集成64 位 AGP 图形控制器，配4MB 独立显存，支持本地图形显示输出。
4. 提供双 10/100Mbps 以太网控制器，前面板带 RJ-45 网口，高速网络通信无需扩展。
5. 内置32 位电气隔离型 PMC 扩展槽，可灵活扩展高速 I/O、通信与专用功能模块。
6. 配备Type I/II IDE+CompactFlash 插槽，支持固态与机械存储，无盘启动更可靠。
7. 集成PCI EIDE 与软驱控制器，可驱动双 EIDE 设备与单软驱，兼容传统存储外设。
8. 提供2 路高速 RS-232 串口、1 路 EPP/ECP 并口、USB、PS/2 键鼠接口，基础 I/O 全面。
9. 支持VME64 总线协议，兼容 A32/A24/A16:D64/D32/D16 主 / 从模式，数据传输高效。
10. 采用6U VME 双槽板卡结构，机械强度高，适配标准工业 VME 机架。
11. 工业级设计，工作温度 0℃~+55℃、存储 - 40℃~+70℃，抗电磁干扰，长期稳定。
12. 内置硬件看门狗、实时时钟（RTC，带电池备份），保障系统异常复位与时间同步。
13. 前面板集成状态 LED，实时显示 CPU、总线与网络状态，便于现场调试诊断。
14. 兼容 XVME-973/974/977 等 breakout 模块，可扩展更多 I/O 接口，配置灵活。
15. 适用于工业自动化、嵌入式控制、数据采集、测试测量、军事 / 航空电子等低功耗高性能场景。

XYCOM XVME-661处理器模块   英文资料：

Product Features of Xycom XVME-661 Processor Module

Xycom XVME-661 is a low-power Pentium III architecture 6U VMEbus high-performance PC compatible processor module, featuring low power consumption, high integration, strong scalability, and industrial stability, suitable for embedded control scenarios with strict energy consumption and reliability requirements.

Equipped with a low-power Intel Pentium III 700MHz processor and built-in 256KB full speed on-chip L2 cache, it balances high performance and low power consumption.

Supports up to 256MB SDRAM (single 144 pin SODIMM) to meet the requirements of complex programs and multitasking.

Integrated 64 bit AGP graphics controller, equipped with 4MB independent video memory, supporting local graphics display output.

Provide dual 10/100Mbps Ethernet controllers with RJ-45 Ethernet ports on the front panel, allowing for high-speed network communication without the need for expansion.

Built in 32-bit electrically isolated PMC expansion slot, which can flexibly expand high-speed I/O, communication, and dedicated functional modules.

Equipped with Type I/II IDE+CompactFlash slots, it supports solid-state and mechanical storage, making diskless booting more reliable.

Integrated PCI EIDE and floppy drive controller, capable of driving dual EIDE devices and single floppy drives, compatible with traditional storage peripherals.

Provide 2 high-speed RS-232 serial ports, 1 EPP/ECP parallel port, USB, PS/2 keyboard and mouse interfaces, with comprehensive basic I/O.

Supports VME64 bus protocol, compatible with A32/A24/A16: D64/D32/D16 master/slave modes, efficient data transmission.

Adopting a 6U VME dual slot board structure, it has high mechanical strength and is compatible with standard industrial VME racks.

Industrial grade design, working temperature range of 0 ℃~+55 ℃, storage range of -40 ℃~+70 ℃, anti electromagnetic interference, long-term stability.

Built in hardware watchdog and real-time clock (RTC, with battery backup) to ensure system abnormal reset and time synchronization.

The front panel integrates status LEDs, which display real-time CPU, bus, and network status for easy on-site debugging and diagnosis.

Compatible with breakout modules such as XVME-973/974/977, expandable with more I/O interfaces, and flexible configuration.

Suitable for low-power and high-performance scenarios such as industrial automation, embedded control, data acquisition, testing and measurement, military/aviation electronics, etc.

XYCOM XVME-661处理器模块   产品展示

产品视频
