XYCOM XVME-675逻辑控制器

1.产 品 资 料 介 绍：

Xycom XVME-675 逻辑控制器（VMEbus PC/AT 处理器模块）

1. 搭载Intel 80486DX4-100MHz 处理器，内置16KB 片上缓存与浮点运算单元，32 位架构，性能较 486DX2 提升约 50%。
2. 支持16MB/32MB 双端口 DRAM，DRAM 控制器带四级双字缓冲，实现零等待状态写入，提升内存访问效率。
3. 集成Super VGA 图形控制器，配1MB 独立显存，最高支持1024×768@256 色，满足本地 HMI 显示需求。
4. 提供32 位 VMEbus 主 / 从接口，兼容 A32/A24/A16 地址空间与 D32/D16 数据传输，支持 VME 中断与字节交换硬件。
5. 内置IDE 硬盘控制器、软驱控制器，支持传统机械存储，适配工业数据存储与系统启动。
6. 配备2 路 RS-232 串口、1 路 EPP 并口、PS/2 键鼠接口，基础外设连接全面。
7. 集成10BASE-T（RJ45）与 10BASE2（BNC）双网络接口，支持工业以太网通信。
8. 提供PC/104 扩展插槽，可直接扩展 I/O、通信与专用功能模块，无需额外载板。
9. 采用单槽 6U VME 板卡结构，机械紧凑，适配标准工业 VME 机架安装。
10. 内置硬件看门狗定时器，支持系统异常自动复位，保障工业场景连续运行。
11. 兼容IBM PC/AT 标准，可直接运行 DOS、Windows、VRTX 等 PC / 实时操作系统，软件生态成熟。
12. 支持Pentium 处理器升级路径（P24T/P24CT 兼容插槽），保护硬件投资。
13. 工业级设计，工作温度 0℃~+55℃，抗电磁干扰，适配工业现场恶劣环境。
14. 前面板集成状态 LED，实时显示 CPU、总线与网络运行状态，便于现场调试与诊断。
15. 适用于工业自动化、DCS/PLC 控制、数据采集、测试测量、军事嵌入式系统等传统工控场景。

XYCOM XVME-675逻辑控制器   英文资料：

Xycom XVME-675 Logic Controller (VMEbus PC/AT Processor Module)

XVME-675 is a single slot 6U VMEbus high-performance PC compatible processor module launched by Xycom, with Intel 486DX4 architecture as the core, integrating PC software ecology and VME bus reliability, focusing on high integration, strong compatibility and industrial stability, suitable for traditional industrial control, data acquisition and embedded real-time scenarios.

Equipped with Intel 80486DX4-100MHz processor, built-in 16KB on-chip cache and floating-point arithmetic unit, 32-bit architecture, performance improved by about 50% compared to 486DX2.

Supports 16MB/32MB dual port DRAM, with a DRAM controller equipped with four level dual word buffer to achieve zero wait state writing and improve memory access efficiency.

Integrated Super VGA graphics controller with 1MB independent video memory, supporting up to 1024 × 768@256 Color meets the local HMI display requirements.

Provide 32-bit VMEbus master/slave interfaces, compatible with A32/A24/A16 address space and D32/D16 data transmission, supporting VME interrupts and byte swapping hardware.

Built in IDE hard drive controller and floppy drive controller, supporting traditional mechanical storage, suitable for industrial data storage and system startup.

Equipped with 2 RS-232 serial ports, 1 EPP parallel port, PS/2 keyboard and mouse interfaces, and comprehensive basic peripheral connections.

Integrated 10BASE-T (RJ45) and 10BASE2 (BNC) dual network interfaces, supporting industrial Ethernet communication.

Provide PC/104 expansion slots that can directly expand I/O, communication, and specialized functional modules without the need for additional carrier boards.

Adopting a single slot 6U VME board structure, it is mechanically compact and compatible with standard industrial VME rack installation.

Built in hardware watchdog timer, supports automatic reset in case of system abnormalities, ensuring continuous operation in industrial scenarios.

Compatible with IBM PC/AT standards, it can directly run PC/real-time operating systems such as DOS, Windows, VRTX, etc., with a mature software ecosystem.

Support upgrade path for Pentium processors (P24T/P24CT compatible slots) to protect hardware investment.

Industrial grade design, working temperature range from 0 ℃ to+55 ℃, anti electromagnetic interference, suitable for harsh environments in industrial sites.

The front panel integrates status LEDs to display real-time CPU, bus, and network operation status, facilitating on-site debugging and diagnosis.

Suitable for traditional industrial control scenarios such as industrial automation, DCS/PLC control, data acquisition, testing and measurement, and military embedded systems.

XYCOM XVME-675逻辑控制器   产品展示

产品视频
