1.产 品 资 料 介 绍：
Xycom XVME-977 磁盘驱动器板
核心特性
- 6U 双高 VME 标准尺寸，仅占用 1 个 VME 总线插槽。
- 内置 2.5 英寸 IDE 硬盘（1.3GB/2.2GB）+ 3.5 英寸 1.44MB 软驱。
- 可选 1.3 英寸 IDE 闪存盘（10MB/20MB/40MB/60MB），无旋转部件更可靠。
- 存储信号通过 VME P2 连接器传输，电源取自 P1 连接器。
- 兼容 Xycom XVME-654/655 等 VME PC/AT 处理器模块。
- 硬盘平均寻道时间约 12ms，道间寻道 4ms，读写性能稳定。
- 支持自动错误重试与缺陷扇区映射，提升数据可靠性。
- 工业级宽温、抗振设计，适配恶劣工况。
- 即插即用，无需额外转接，安装部署便捷。
- 提供标准 IDE 接口，兼容主流工业操作系统。
- 板载电源管理，为存储设备提供稳定供电。
- 信号完整性优化，长距离传输无衰减。
- 支持单 / 双盘配置，满足不同容量需求。
- 兼容 VMEbus IEEE 1014 标准，无缝接入现有系统。
- 提供 1 年质保，工业级可靠性保障。
Xycom XVME-977磁盘驱动器板 英文资料：
Xycom XVME-977 Disk Drive Board
Xycom XVME-977 is a 6U dual slot industrial grade disk storage module designed specifically for VMEbus systems, integrating IDE hard drives/floppy drives or solid-state flash memory. It achieves local high-capacity storage for VME systems with a single slot and is suitable for harsh industrial control scenarios.
Core Features
6U dual high VME standard size, occupying only one VME bus slot.
Built in 2.5-inch IDE hard drive (1.3GB/2.2GB)+3.5-inch 1.44MB floppy drive.
Optional 1.3-inch IDE flash drive (10MB/20MB/40MB/60MB), with no rotating parts for greater reliability.
The storage signal is transmitted through the VME P2 connector, and the power is taken from the P1 connector.
Compatible with VME PC/AT processor modules such as Xycom XVME-654/655.
The average seek time of the hard drive is about 12ms, the inter track seek time is 4ms, and the read and write performance is stable.
Support automatic error retry and defect sector mapping to improve data reliability.
Industrial grade wide temperature and anti vibration design, suitable for harsh working conditions.
Plug and play, no need for additional adapters, easy to install and deploy.
Provide standard IDE interface, compatible with mainstream industrial operating systems.
Onboard power management provides stable power supply for storage devices.
Signal integrity optimization, with no attenuation during long-distance transmission.
Supports single/dual disk configuration to meet different capacity requirements.
Compatible with VMEbus IEEE 1014 standard, seamlessly integrated into existing systems.
Provide 1-year warranty and industrial grade reliability guarantee.
Xycom XVME-977磁盘驱动器板 产品展示
