XYCOM 3115T工业触摸监视器面板

1.产 品 资 料 介 绍：

XYCOM 3115T 工业触摸监视器面板

核心特点

1. 15 英寸彩色 TFT 液晶，XGA 分辨率 1024×768，色彩还原准确，显示清晰稳定。
2. 8 线模拟电阻式触摸屏（4H 表面硬度），支持精准触控，适配带手套操作的工业现场。
3. 前面板 NEMA 4/12 与 IP65 防护等级，密封设计防尘防溅，耐受车间油污与水汽。
4. 搭载 Intel Socket 370 架构 Celeron/Pentium III 处理器（可选 850MHz/1.2GHz），性能满足工业 HMI 与控制程序运行。
5. 标配 256MB SDRAM，可扩展至 512MB，提升多任务处理效率。
6. 内置 10/100Base-T 以太网端口，支持高速工业网络通信与远程监控。
7. 集成 2 路 RS-232、1 路可配置 RS-232/422/485 串口，USB、并口、VGA 等完备 I/O。
8. 1 个半长 PCI 扩展槽，方便加装现场总线或特殊通信模块。
9. 支持 Windows 2000/XP、MS-DOS 等主流工业操作系统，驱动兼容性强。
10. 宽温运行（0℃~50℃），抗振动、抗电磁干扰，符合工业 IEC 标准。
11. 100–240VAC 宽电压供电（50/60Hz），具备过压、过流保护。
12. 内置 IDE 硬盘、软驱、超薄 CD-ROM 位，可选闪存模块，满足程序与数据存储。
13. 平板嵌入式安装，结构紧凑，全金属机箱，被动散热为主，减少风扇故障风险。
14. 自带诊断 LED 与亮度调节，方便现场状态查看与显示参数调整。
15. 符合 CE、UL 认证，长期备品支持，适合老旧工业系统的升级与替换。

 XYCOM 3115T工业触摸监视器面板   英文资料：

XYCOM 3115T Industrial Touch Monitor Panel

XYCOM 3115T is a Thinline series 15 inch industrial grade integrated touch tablet PC that combines compact structure with industrial grade high reliability. It is designed to provide stable human-machine interaction solutions for demanding industrial scenarios such as production line monitoring, equipment control, and process visualization.

Core Features

15 inch color TFT LCD with XGA resolution of 1024 × 768, accurate color reproduction, clear and stable display.

8-wire analog resistive touch screen (4H surface hardness), supporting precise touch control, suitable for industrial sites with glove operation.

The front panel has a NEMA 4/12 and IP65 protection rating, with a sealed design that is dust-proof and splash proof, and can withstand workshop oil and moisture.

Equipped with Intel Socket 370 architecture Celeron/Pentium III processor (optional 850MHz/1.2GHz), the performance meets the requirements for industrial HMI and control program operation.

Standard 256MB SDRAM, expandable to 512MB, improves multitasking efficiency.

Built in 10/100Base-T Ethernet port, supporting high-speed industrial network communication and remote monitoring.

Integrate 2 RS-232 channels and 1 configurable RS-232/422/485 serial port, USB、 Complete I/O capabilities such as parallel port and VGA.

1 and a half long PCI expansion slots for easy installation of fieldbus or special communication modules.

Supports mainstream industrial operating systems such as Windows 2000/XP and MS-DOS, with strong driver compatibility.

Wide temperature operation (0 ℃~50 ℃), anti vibration, anti electromagnetic interference, in compliance with industrial IEC standards.

100-240VAC wide voltage supply (50/60Hz), with overvoltage and overcurrent protection.

Built in IDE hard drive, floppy drive, ultra-thin CD-ROM slot, optional flash module to meet program and data storage needs.

Tablet embedded installation, compact structure, all metal chassis, passive heat dissipation as the main feature, reducing the risk of fan failure.

Equipped with diagnostic LED and brightness adjustment, convenient for on-site status viewing and display parameter adjustment.

Compliant with CE and UL certifications, with long-term spare parts support, suitable for upgrading and replacing old industrial systems.

 XYCOM 3115T工业触摸监视器面板   产品展示
