Xycom 8500操作监视器面板

1.产 品 资 料 介 绍：

Xycom 8500 操作监视器面板

核心特点

1. 单色高对比度 CRT 显示屏，显示清晰无拖影，适配车间强光与昏暗环境，支持字符 / 图形显示模式。
2. 前面板符合 NEMA 4/12（IP65）防护标准，全密封设计，防尘防油污防溅水，耐受工业恶劣工况。
3. 集成矩阵式数字按键 + 功能按键区，搭配旋转调节旋钮，支持本地快速参数输入与模式切换。
4. 兼容工业标准通信接口（RS-232 为主，可选 RS-422/485），可直接对接主流 PLC 与 RTU 设备。
5. 宽电压双路供电（115/230VAC，50/60Hz，1.5/0.75A），全球工业电网通用，具备过压过流保护。
6. 无风扇纯被动散热，全金属机箱，避免粉尘进入与风扇故障导致的停机，提升系统 MTBF。
7. 宽温工作范围（0℃~50℃），抗强振动、抗电磁干扰（EMI/RFI），符合 IEC/EN 工业标准。
8. 内置多组诊断指示灯，可快速定位电源、通信、显示等关键模块的运行状态。
9. 支持 19 英寸标准机架安装或现场面板嵌入式安装，安装方式灵活，适配控制室与现场柜布局。
10. 模块化设计，关键部件可快速拆卸更换，三颗固定螺丝即可完成维护，大幅缩短停机时间。
11. 支持工业级字符型 HMI 软件与 DOS 底层驱动，兼容早期工业控制程序，无需大规模二次开发。
12. 标配硬件看门狗电路，可自动检测系统死机并执行复位，保障无人值守工况下的持续运行。
13. 符合 UL、CE、CSA 工业认证，具备完善的电气隔离与浪涌保护设计。
14. 低功耗稳定运行，适合偏远地区、无空调机房的长期部署，降低运维成本。
15. 长期备品备件渠道完善，适合老旧工业系统的替换与升级，避免因设备停产导致的系统瘫痪。

Xycom 8500操作监视器面板  英文资料：

Xycom 8500 Operation Monitor Panel

Xycom 8500 is a classic heavy-duty industrial operator monitor designed for harsh on-site operations in refining, chemical, power, metallurgy, and other industries. It integrates dedicated display screens and physical keypad areas, supports panel/rack installation, and has strong protection and anti-interference capabilities. It is the core human-machine interaction device of early DCS/PLC systems.

Core Features

Monochrome high contrast CRT display screen, clear display without ghosting, suitable for strong and dim workshop environments, supports character/graphic display modes.

The front panel meets the NEMA 4/12 (IP65) protection standard, with a fully sealed design that is dustproof, oil resistant, splash proof, and can withstand harsh industrial conditions.

Integrated matrix digital buttons+function button area, paired with a rotating adjustment knob, supporting local fast parameter input and mode switching.

Compatible with industrial standard communication interfaces (primarily RS-232, optional RS-422/485), it can directly interface with mainstream PLC and RTU devices.

Wide voltage dual power supply (115/230VAC, 50/60Hz, 1.5/0.75A), universal for industrial power grids worldwide, with overvoltage and overcurrent protection.

Fanless pure passive cooling, all metal chassis, to prevent dust from entering and downtime caused by fan failure, and to improve system MTBF.

Wide temperature working range (0 ℃~50 ℃), resistant to strong vibration and electromagnetic interference (EMI/RFI), in compliance with IEC/EN industrial standards.

Built in multiple diagnostic indicator lights can quickly locate the operating status of key modules such as power supply, communication, and display.

Supports 19 inch standard rack installation or on-site panel embedded installation, with flexible installation methods and adaptability to control room and on-site cabinet layouts.

Modular design, key components can be quickly disassembled and replaced, and maintenance can be completed with three fixed screws, greatly reducing downtime.

Supports industrial grade character based HMI software and DOS underlying drivers, compatible with early industrial control programs, without the need for large-scale secondary development.

The standard hardware watchdog circuit can automatically detect system crashes and perform resets, ensuring continuous operation under unmanned conditions.

Compliant with UL, CE, and CSA industrial certifications, with comprehensive electrical isolation and surge protection design.

Low power stable operation, suitable for long-term deployment in remote areas and air-conditioned computer rooms, reducing operation and maintenance costs.

Long term spare parts channels are well-established, suitable for replacing and upgrading old industrial systems, to avoid system paralysis caused by equipment shutdown.

Xycom 8500操作监视器面板   产品展示

产品视频
