1746-HSRV 运动控制模块

1.产 品 资 料 介 绍：

1746-HSRV 运动控制模块介绍

1. 属于 SLC 500 平台专用单轴伺服控制模块
2. 支持位置、速度、扭矩三种闭环控制模式
3. 适配 SLC 5/03、5/04、5/05 系列 CPU 处理器
4. 支持增量式 A/B/Z 相编码器信号反馈
5. 具备 32 位高精度位置计数功能
6. 输出 ±10V 模拟量信号驱动伺服驱动器
7. 支持绝对定位、相对定位、速度运行模式
8. 内置多种原点回归模式，方便设备校准
9. 与 CPU 通过数据字进行独立运动数据交互
10. 板载 LED 指示灯显示运行、故障、编码器状态
11. 安装于 SLC 500 标准 1746 机架插槽
12. 由背板 5V DC 供电，无需额外外部电源
13. 具备编码器断线、位置超差、过载等保护功能
14. 广泛应用于定位、裁切、包装等精密设备
15. 该型号已停产，市场以二手、翻新备件为主

1746-HSRV 运动控制模块 英文资料：

1746-HSRV motion control module introduction

1746-HSRV is a Rockwell SLC 500 series dedicated servo motion control module used for single axis high-precision closed-loop motion control. The following is a detailed introduction:

Belonging to the SLC 500 platform dedicated single axis servo control module

Supports three closed-loop control modes: position, speed, and torque

Compatible with SLC 5/03, 5/04, 5/05 series CPU processors

Support incremental A/B/Z phase encoder signal feedback

Equipped with 32-bit high-precision position counting function

Output ± 10V analog signal to drive servo driver

Support absolute positioning, relative positioning, and speed operation modes

Built in multiple origin regression modes for easy device calibration

Independent motion data interaction with CPU through data words

Onboard LED indicator lights display running, fault, and encoder status

Installed in SLC 500 standard 1746 rack slot

Powered by 5V DC from the backplane, no additional external power supply required

Equipped with protection functions such as encoder disconnection, position deviation, overload, etc

Widely used in precision equipment such as positioning, cutting, packaging, etc

This model has been discontinued, and the market mainly consists of second-hand and refurbished spare parts

In summary, 1746-HSRV is the core module of SLC 500 system for achieving precision servo motion control. It relies on encoder feedback and analog output to achieve stable closed-loop control and is an important spare part for old automation equipment.
