2711-T10C15触摸屏面板

2711-T10C15触摸屏面板

1.产 品 资 料 介 绍：

1. 属于 Allen‑Bradley PanelView Standard 1000 系列纯触摸屏工业 HMI，已官方停产，主打 ControlNet 通信场景的操作员监控与控制。
2. 10.4 英寸（10 英寸级）彩色 TFT 显示屏，分辨率 640×480，背光典型半寿命 50000 小时。
3. 采用模拟电阻式单点触摸屏，无需键盘，适合快速触控操作，点击寿命达百万次。
4. 前面板防护等级 NEMA 4X/IP65，防尘防水，适配户外及恶劣工业车间。
5. 标配ControlNet 通信端口+RS‑232 打印机专用端口，区别于 DeviceNet 版本的 2711‑T10C10。
6. 宽电压 AC 供电 85–264 VAC、47–63 Hz，全球通用电网，建议独立接地与过流保护。
7. 典型功耗约 39 W，工业级电源设计，长期运行稳定。
8. 内置 256 KB 非易失性用户闪存，用于存储画面、配方、报警数据。
9. 配置软件为 PanelBuilder32/RSView32，支持多语言界面与批量程序部署。
10. 工作温度 0–55℃，存储温度‑25–70℃，5–95% 无凝露湿度耐受。
11. 具备工业级抗振动、抗冲击性能，EMC 符合 IEC 相关标准，抗强电磁干扰。
12. 支持 ATA 卡进行程序备份、恢复与多台设备的快速克隆。
13. 面板嵌入式安装，严禁带电插拔 ControlNet 总线与电源线，接地需符合 ControlNet 系统规范。
14. 通过 CE、c‑UR‑us、C‑Tick 等国际安全与电磁兼容认证，可用于欧美澳市场。
15. 停产推荐升级型号为 PanelView Plus 1000 系列（如 2711P‑T10C21D8S），升级需重新开发 HMI 程序并调整通信网络拓扑。

2711-T10C15触摸屏面板 英文资料：

Belonging to the Allen Bradley PanelView Standard 1000 series pure touch screen industrial HMI, it has been officially discontinued and focuses on operator monitoring and control in ControlNet communication scenarios.

10.4-inch (10 inch level) color TFT display screen, resolution 640 × 480, typical backlight half life of 50000 hours.

Adopting analog resistive single point touch screen, no keyboard required, suitable for fast touch operation, with a click life of millions of times.

The front panel protection level is NEMA 4X/IP65, dustproof and waterproof, suitable for outdoor and harsh industrial workshops.

Standard ControlNet communication port+RS-232 printer specific port, different from DeviceNet version 2711-T10C10.

Wide voltage AC power supply 85-264 VAC, 47-63 Hz, global power grid, recommended independent grounding and overcurrent protection.

Typical power consumption of about 39 W, industrial grade power supply design, stable long-term operation.

Built in 256 KB non-volatile user flash memory for storing images, formulas, and alarm data.

The configuration software is PanelBuilder32/RSView32, which supports multilingual interfaces and batch program deployment.

Working temperature 0-55 ℃, storage temperature -25-70 ℃, 5-95% no condensation humidity tolerance.

It has industrial grade anti vibration and anti impact performance, EMC meets relevant IEC standards, and is resistant to strong electromagnetic interference.

Support ATA card for program backup, recovery, and fast cloning of multiple devices.

Embedded installation on the panel, it is strictly prohibited to plug and unplug the ControlNet bus and power cord with power on, and grounding must comply with the ControlNet system specifications.

Through international safety and electromagnetic compatibility certifications such as CE, C-UR-US, and C-Tick, it can be used in the European, American, and Australian markets.

The recommended upgrade model for discontinuation is PanelView Plus 1000 series (such as 2711P-T10C21D8S), which requires redeveloping the HMI program and adjusting the communication network topology.

Overall, 2711-T10C15 is a classic 10 inch touchscreen HMI under the traditional ControlNet network, currently in service on a large number of existing devices; Its core advantages lie in high protection, native compatibility with ControlNet, and wide voltage power supply; When upgrading and migrating, program refactoring and communication protocol/hardware adaptation are the two core tasks.

2711-T10C15触摸屏面板 产品展示
