DSQC327A 3HAC17971-1/05模拟输出模块

1.产 品 资 料 介 绍：

ABB DSQC327A 3HAC17971-1/05 模拟输出模块（组合 I/O）

1. 品牌型号：ABB DSQC327A，物料号 3HAC17971-1/05，IRC5 平台组合 I/O 模块。
2. 适配系统：IRC5 全系列控制器（Compact/Single/M2004），兼容 IRB 120/1410/2600/4600/6700/7600 等机器人。
3. 核心功能：2 路模拟输出（AO）+16 路数字输入（DI）+16 路数字输出（DO），实现模拟量控制与开关量信号一体化处理。
4. 模拟输出规格：2 通道，4–20mA 电流型，精度 ±0.1% FS，12 位分辨率，用于控制阀门、电机转速、比例阀等。
5. 数字 I/O 规格：16 路 DI（24V DC，NPN/PNP 兼容，最大 5mA）；16 路 DO（24V DC，晶体管输出，单路最大 0.5A，响应 < 1ms）。
6. 信号隔离：通道间电气隔离（2500V AC），强抗干扰，保障工业环境稳定。
7. 通信方式：IRC5 内部总线，即插即用，系统自动识别，无需额外驱动。
8. 供电：24V DC±20%，由控制器背板供电。
9. 状态指示：LED 显示运行、通信、通道故障状态。
10. 安装方式：IRC5 控制柜扩展插槽直插，支持热插拔（部分机型）。
11. 物理参数：尺寸约 2.2×12.4×12.6cm，重量约 0.1kg，防护等级 IP20。
12. 环境适应：工作温度 - 25℃~+60℃，存储 - 40℃~+85℃，湿度 5%~95%（无冷凝）。
13. 诊断功能：实时自检，支持短路、断路、过流等故障上报与定位。
14. 应用场景：机器人精密装配、喷涂、焊接、搬运，以及过程控制中的模拟量调节。
15. 产品状态：已停产，为 IRC5 系统经典备件，市场以翻新 / 库存为主。

DSQC327A 3HAC17971-1/05模拟输出模块 英文资料：

ABB DSQC327A 3HAC17971-1/05 Analog Output Module (Combination I/O)

DSQC327A (3HAC17971-1/05) is a specialized digital+analog combination I/O module for ABB IRC5 robot controllers. The core provides 2 high-precision analog outputs and integrates 16 digital I/O channels for precise analog control and switch signal processing of robot systems.

Brand and model: ABB DSQC327A, material number 3HAC17971-1/05, IRC5 platform combination I/O module.

Adaptation system: IRC5 full series controller (Compact/Single/M2004), compatible with IRB 120/140/2600/4600/6700/7600 and other robots.

Core function: 2 analog outputs (AO)+16 digital inputs (DI)+16 digital outputs (DO), achieving integrated processing of analog control and switch signals.

Analog output specifications: 2-channel, 4-20mA current type, accuracy ± 0.1% FS, 12 bit resolution, used for controlling valves, motor speed, proportional valves, etc.

Digital I/O specifications: 16 DI (24V DC, compatible with NPN/PNP, maximum 5mA); 16 channels of DO (24V DC, transistor output, maximum 0.5A per channel, response<1ms).

Signal isolation: Electrical isolation between channels (2500V AC), strong anti-interference, ensuring stable industrial environment.

Communication method: IRC5 internal bus, plug and play, automatically recognized by the system, no additional driver required.

Power supply: 24V DC ± 20%, powered by the controller backplane.

Status indication: LED displays the status of operation, communication, and channel faults.

Installation method: IRC5 control cabinet expansion slot direct insertion, supports hot plugging (some models).

Physical parameters: Size approximately 2.2 × 12.4 × 12.6cm, weight approximately 0.1kg, protection level IP20.

Environmental adaptation: working temperature -25 ℃~+60 ℃, storage -40 ℃~+85 ℃, humidity 5%~95% (no condensation).

Diagnostic function: Real time self check, supports reporting and locating faults such as short circuit, open circuit, and overcurrent.

Application scenarios: Robot precision assembly, spraying, welding, handling, and analog quantity adjustment in process control.

Product status: discontinued, a classic spare part for the IRC5 system, mainly for refurbishment/inventory in the market.

This module is characterized by high integration, high-precision analog output, and strong anti-interference, and is a key component for implementing complex analog control in the IRC5 robot system.

DSQC327A 3HAC17971-1/05模拟输出模块 产品展示

产品视频
