INICT03A计算机传输模块

INICT03A计算机传输模块

1.产 品 资 料 介 绍：

1. 适配 ABB Symphony、INFI 90 DCS 系统，作为 Infi-Net/Cnet 与上位机的通信网关
2. 核心功能为计算机与控制系统间的数据高速传输、远程监控与参数配置
3. 标配 2 路 RS-232-C 串口（速率 50–19,200bps 可选）+1 路 SCSI 高速接口（4MB/s）
4. 内存配置 512KB ROM、2MB RAM，支持最多 30,000 点变量定义
5. 背板 + 5V DC 供电，典型功耗约 10W，支持 ±10% 宽电压
6. 单槽标准机架安装，支持热插拔，在线维护不中断运行
7. 工业级设计，工作温度 0–60℃，湿度 5%–95%（无凝露），防护等级 IP20
8. 内置光电隔离与数据校验，抗干扰强，保障传输稳定可靠
9. 兼容 INFI 90 原生协议，可对接 Modbus RTU/TCP、Profibus-DP 等外部系统
10. 支持双通道硬件冗余，故障切换时间＜10ms，确保通信不中断
11. 内置诊断与状态指示，便于快速定位通信异常
12. 插孔板接线方式，抗振动、接触牢固，适应现场工况
13. 符合 CE、UL 等工业安全与电磁兼容标准
14. 广泛用于电力、冶金、化工等大型过程自动化系统的上位机集成
15. 低功耗、无风扇设计，寿命长、故障率低，适合长期连续运行

INICT03A计算机传输模块 英文资料：

INICT03A is the computer transmission module (ICT) of ABB Bailey Symphony/INFI 90 system, serving as a high-speed communication bridge between Infi Net/Cnet and the upper computer, enabling bidirectional data exchange and system monitoring.

Compatible with ABB Symphony and INFI 90 DCS systems, serving as a communication gateway between Infi Net/Cnet and the upper computer

The core function is high-speed data transmission, remote monitoring, and parameter configuration between computers and control systems

Standard configuration includes 2 RS-232-C serial ports (speed 50-19200bps optional) and 1 SCSI high-speed interface (4MB/s)

Memory configuration: 512KB ROM, 2MB RAM, supporting up to 30000 variable definitions

Backboard+5V DC power supply, typical power consumption of about 10W, supports ± 10% wide voltage

Single slot standard rack installation, supports hot swapping, online maintenance without interruption of operation

Industrial grade design, working temperature 0-60 ℃, humidity 5% -95% (no condensation), protection level IP20

Built in photoelectric isolation and data verification, strong anti-interference, ensuring stable and reliable transmission

Compatible with INFI 90 native protocol, can interface with external systems such as Modbus RTU/TCP, Profibus DP, etc

Support dual channel hardware redundancy, with a fault switching time of less than 10ms, ensuring uninterrupted communication

Built in diagnostics and status indicators for quick identification of communication anomalies

Jack board wiring method, anti vibration, firm contact, suitable for on-site working conditions

Compliant with industrial safety and electromagnetic compatibility standards such as CE and UL

Widely used for upper computer integration in large-scale process automation systems such as power, metallurgy, and chemical engineering

Low power consumption, fanless design, long lifespan, low failure rate, suitable for long-term continuous operation

This module is a key component of the DCS system upper computer integration, which is stable, efficient, and adaptable, and can meet the high reliability communication needs of industrial sites.

INICT03A计算机传输模块 产品展示
