AMAT Applied Materials 0660-01879印刷电路板

AMAT Applied Materials 0660-01879印刷电路板

1.产 品 资 料 介 绍：

核心规格

功能特点

• 高速通信：DeviceNet 接口，支持实时数据传输与设备状态监控。
• 高精度采集：通道独立光电隔离，抗干扰能力强。
• 灵活配置：I/O 通道可根据工艺需求扩展或重组。
• 状态可视化：每路配备双色 LED，实时显示信号状态。
• 安全防护：具备过压、欠压、短路保护，符合 SEMI S2 安全标准。

典型应用

• 晶圆传输系统的位置检测与控制
• 工艺腔室门联锁与安全信号处理
• 设备运行状态监测与故障报警

AMAT Applied Materials 0660-01879印刷电路板 英文资料：

AMAT Applied Materials 0660-01879 is a printed circuit board for DeviceNet digital I/O controllers, suitable for semiconductor device digital signal acquisition and control. It is commonly used in etching, thin film deposition and other systems to accurately collect sensor signals and control actuators, ensuring process stability and repeatability.

Core specifications

Project specification remarks

Application series of 300mm wafer platforms such as etching, thin film deposition CMP

Functional digital I/O control and communication compatible with DeviceNet protocol

Interface type DeviceNet (RJ-45 or M12) supports speeds of 125/250/500 kbps

I/O channels 16-32 channels (configurable), typical 24 channels, 8 inputs and 16 outputs

Input signal dry contact, NPN/PNP proximity switch photoelectric isolation

Output type relay, transistor (NPN/PNP) driving capability ≤ 24 VDC/2 A

Working voltage 24 VDC ± 10% monorail power supply

Material 316L stainless steel (contact), FR-4 substrate corrosion-resistant, low adsorption

Protection level IP20 dustproof and splash proof

Installation of standard cabinet with dimensions of approximately 200 × 150 × 30 mm

Features

High speed communication: DeviceNet interface, supporting real-time data transmission and device status monitoring.

High precision acquisition: Channel independent optoelectronic isolation, strong anti-interference ability.

Flexible configuration: I/O channels can be expanded or reorganized according to process requirements.

Status visualization: Each channel is equipped with dual color LEDs to display signal status in real-time.

Safety protection: Equipped with overvoltage, undervoltage, and short-circuit protection, in compliance with SEMI S2 safety standards.

Typical Applications

Position detection and control of wafer transfer system

Process chamber door interlocking and safety signal processing

Equipment operation status monitoring and fault alarm
