AMAT Applied Materials 0040-20518适配器

AMAT Applied Materials 0040-20518适配器

1.产 品 资 料 介 绍：

关键参数

功能特点

• 多通道兼容：支持电气、气动、真空三种通道独立转接，减少额外布线。
• 低插入损耗：信号通道采用低阻抗设计，确保高速信号稳定传输。
• 快速更换：采用自锁定或防错接口，更换便捷，降低停机时间。
• 高可靠性：适应晶圆制造环境的高洁净度与频繁启停要求。

典型应用

• 刻蚀（Etch）与化学气相沉积（CVD）系统的控制信号转接
• 物理气相沉积（PVD）设备的气体管路延长
• 晶圆传输腔室的真空通道连接

AMAT Applied Materials  0040-20518适配器  英文资料：

AMAT Applied Materials 0040-20518 is a specialized adapter used to connect cables or modules with different interfaces in semiconductor devices such as Centura, Endura, P5000, etc., to achieve signal/gas/vacuum channel switching and extension.

key parameters

Project specification remarks

Adapt to multi chamber wafer manufacturing systems such as Centura, Endura, P5000, Producer, etc

The interface types are mostly circular or rectangular connectors, some of which include air/vacuum interfaces that match the original equipment interface

Functional positioning signal/gas/vacuum channel conversion, extension can be connected in series or parallel

Working temperature -20 ℃~60 ℃ depending on material and sealing grade

Applicable media include electrical signals, process gases, and vacuum non corrosive media

Material engineering plastic or metal body, gold-plated/nickel plated contacts for corrosion resistance and wear resistance

Installation method: Panel installation, direct insertion or flange fixation for easy maintenance

Features

Multi channel compatibility: supports independent switching of electrical, pneumatic, and vacuum channels, reducing additional wiring.

Low insertion loss: The signal channel adopts a low impedance design to ensure stable transmission of high-speed signals.

Quick replacement: Using self locking or error proof interfaces, easy replacement and reduced downtime.

High reliability: Adapt to the high cleanliness and frequent start stop requirements of wafer manufacturing environment.

Typical Applications

Control signal transfer between Etch and CVD systems

Gas pipeline extension for physical vapor deposition (PVD) equipment

Vacuum channel connection of wafer transfer chamber

AMAT Applied Materials  0040-20518适配器 产品展示

 产品视频
