AMAT Applied Materials 0100-66026输入输出模块

AMAT Applied Materials  0100-66026输入输出模块

1.产 品 资 料 介 绍：

核心规格

功能特点

• 高隔离设计：数字量通道采用光电隔离，模拟量通道采用隔离放大器，有效抑制电磁干扰。
• 独立通道保护：每路输出均有过流、过压保护，单路故障不影响其他通道。
• 状态可视化：通道状态通过 LED 实时显示，便于现场诊断。
• 高精度模拟量：16 位 ADC/DAC，满足精密控制需求。
• 紧凑结构：3U 板型，节省控制柜空间。

AMAT Applied Materials 0100-66026输入输出模块  英文资料：

AMAT Applied Materials 0100-66026 is an input/output (I/O) module specifically designed for semiconductor devices, primarily used for chamber control, valve actuation, and sensor signal acquisition. This module is in the form of a printed circuit board (PCB), integrating digital and analog channels, communicating with the main controller through a backplane bus, and has high isolation, low power consumption, and anti-interference capabilities.

Core specifications

Project Specification Description

Channel type: mixed channel of digital input/output and analog input/output, meeting various control requirements

Digital input with 8 channels of photoelectric isolation 24V DC input, isolation voltage ≥ 2500Vrms

Digital output 8-way relay/transistor output single load capacity: AC 250V/3A or DC 30V/5A

Analog input 4-channel differential input supports 0~10V, 4~20mA signals

Analog output 2-channel current/voltage output 0~10V or 4~20mA, accuracy ± 0.1%

Communication interface dedicated backplane bus (non-standard) directly connected to AMAT system backplane

Working voltage 24V DC ± 10%, typical power consumption is about 8W

Operating temperature range of 0 ℃~50 ℃, suitable for industrial grade environments

Size approximately 270mm × 140mm × 30mm 3U standard plate type

Installation method: Backboard slot type needs to be used in conjunction with AMAT backboard

Features

High isolation design: The digital channel adopts optoelectronic isolation, and the analog channel adopts isolation amplifier to effectively suppress electromagnetic interference.

Independent channel protection: Each output has overcurrent and overvoltage protection, and a single channel fault does not affect other channels.

Status visualization: The channel status is displayed in real-time through LED, which facilitates on-site diagnosis.

High precision analog: 16 bit ADC/DAC, meeting the requirements of precision control.

Compact structure: 3U board type, saving control cabinet space.
