1.产 品 资 料 介 绍：
- 专为 DeltaV SIS 安全系统设计，适配安全数字量输出回路
- 提供 8 路独立继电器输出通道
- 每路采用单刀双掷 SPDT 触点结构
- 线圈供电为系统标准 24 VDC
- 触点容量支持 250 VAC/2.5A、30 VDC/2.5A 电阻负载
- 线圈与触点间高电气隔离，保护系统卡件
- 通道间相互隔离，提升抗干扰与安全性
- 自带通道动作状态指示，便于现场调试与巡检
- 需搭配 KJ2231X1‑BC1 二极管模块实现续流保护
- 支持 DIN 导轨安装，结构紧凑、布线规范
- 宽温工作环境，适应恶劣工业现场
- 抗振动、抗冲击，满足长期稳定运行
- 符合 IEC 61508 标准，可达 SIL3 安全等级
- 具备防爆相关认证，可用于危险区域场合
- 主要用于 ESD 紧急停车、安全关断阀等联锁控制
KJ2231X1-EA1继电器模块 英文资料：
KJ2231X1-EA1 is a specialized relay output module for Emerson DeltaV SIS safety instrumented system, used for signal isolation and on-site load driving of safety interlock circuits, meeting high safety level and industrial reliable operation requirements.
Specially designed for DeltaV SIS safety system, compatible with safety digital output circuit
Provide 8 independent relay output channels
Each circuit adopts a single pole double throw SPDT contact structure
The coil is powered by the system standard 24 VDC
Contact capacity supports 250 VAC/2.5A, 30 VDC/2.5A resistive loads
High electrical isolation between coils and contacts, protecting system cards
Isolation between channels enhances anti-interference and safety
Equipped with channel action status indication, convenient for on-site debugging and inspection
Need to be paired with KJ2231X1-BC1 diode module to achieve freewheeling protection
Supports DIN rail installation, compact structure, and standardized wiring
Wide temperature working environment, suitable for harsh industrial sites
Anti vibration and anti impact, meeting long-term stable operation requirements
Compliant with IEC 61508 standard, up to SIL3 safety level
Has explosion-proof certification and can be used in hazardous areas
Mainly used for interlocking control of ESD emergency stop, safety shut-off valve, etc
ending
This module has a reliable structure and is easy to maintain. It is a core supporting component for safety output circuits in high-risk scenarios such as petrochemicals, natural gas, and coal chemical industries.
KJ2231X1-EA1继电器模块 产品展示
