IC697MEM713存储模块

IC697MEM713存储模块

1.产 品 资 料 介 绍：

一、核心定位与关键特性

1. 类型与容量：CMOS 静态 RAM 扩展子板，标准容量64KB，可配置为程序存储或数据存储。
2. 适配对象：仅支持IC697CPU771、IC697CPU772 CPU 模块，以及IC697PCM711可编程协处理器模块。
3. 安装方式：作为 ** 子板（Daughter Board）** 直接安装在对应 CPU/PCM 模块上，与母板共用插槽，不额外占用机架槽位。
4. 掉电保持：依赖 CPU/PCM 主板上的后备电池维持数据，断电后内容不丢失。
5. 可靠性：CPU 后台持续校验程序内存；PCM 在上电 / 复位时校验存储区，保障数据完整性。
6. 兼容性：与 Series 90-70 标准机架、背板及编程软件（Logicmaster 90、Proficy Machine Edition）完全兼容。

二、技术规格

• 所属系列：GE Fanuc Series 90-70
• 存储类型：CMOS SRAM
• 标准容量：64KB（另有 128KB/256KB/512KB 同系列型号）
• 工作电压：由母板（CPU/PCM）供电，无需外部电源
• 掉电保持：主板电池供电，数据永久保持
• 安装位置：CPU/PCM 模块内部子板插槽
• 环境温度：0–60℃（工业标准）
• 错误校验：CPU 后台实时校验；PCM 上电 / 复位校验

三、功能与应用场景

• 程序扩容：为复杂逻辑、多任务控制程序提供额外存储空间，解决 CPU 自带内存不足问题。
• 数据存储：用于保存过程数据、配方参数、历史记录、报警信息等非易失性数据。
• 协处理器支持：为 PCM711 的 MegaBasic 程序与数据采集任务提供内存扩展。
• 典型应用：汽车生产线、冶金、电力、水处理、物料搬运等中大型 PLC 控制系统。

IC697MEM713存储模块 英文资料：

IC697MEM713 is a 64KB CMOS expansion storage motherboard for GE Fanuc Series 90-70 series, designed to provide program and data memory expansion for CPU 771/772 and PCM711 without occupying additional slots. Data is held by the motherboard battery during power outages.

1、 Core positioning and key characteristics

Type and Capacity: CMOS Static RAM Expansion Board, standard capacity 64KB, configurable for program storage or data storage.

Adaptation object: Only supports IC697CP771, IC697CP772 CPU modules, and IC697PCM711 programmable coprocessor module.

Installation method: As a * * Daughter Board * *, it is directly installed on the corresponding CPU/PCM module, sharing the same slot with the motherboard without occupying additional rack slots.

Power down maintenance: relies on the backup battery on the CPU/PCM motherboard to maintain data, and the content is not lost after power failure.

Reliability: CPU background continuously verifies program memory; PCM verifies the storage area during power on/reset to ensure data integrity.

Compatibility: Fully compatible with Series 90-70 standard rack, backplane, and programming software (Logicmaster 90, Proficy Machine Edition).

2、 Technical specifications

Series: GE Fanuc Series 90-70

Storage type: CMOS SRAM

Standard capacity: 64KB (there are also 128KB/256KB/512KB models in the same series)

Working voltage: Powered by the motherboard (CPU/PCM), no external power supply required

Power down maintenance: Powered by the motherboard battery, data is permanently retained

Installation position: CPU/PCM module internal motherboard slot

Environmental temperature: 0-60 ℃ (industrial standard)

Error verification: Real time CPU backend verification; PCM power on/reset verification

3、 Function and application scenarios

Program expansion: Provides additional storage space for complex logic and multitasking control programs, solving the problem of insufficient CPU built-in memory.

Data storage: used to store non-volatile data such as process data, formula parameters, historical records, alarm information, etc.

Coprocessor support: Provides memory expansion for MegaBasic programs and data acquisition tasks of PCM711.

Typical applications: Large scale PLC control systems for automotive production lines, metallurgy, power, water treatment, material handling, and other industries.
