IC697PWR720可编程控制器

1.产 品 资 料 介 绍：

IC697PWR720 电源适配模块简介

1. 属于 Series 90‑70 PLC 系统，安装于机架电源专用槽位。
2. 核心功能：转接外部电源至背板，提供 + 5VDC、+12VDC、‑12VDC 三路输出。
3. 单槽设计，占用 1 个机架插槽。
4. 输出规格：+5VDC/18A、+12VDC/2A、‑12VDC/1A。
5. 自身仅需背板 5V 总线提供 50mA 工作电流。
6. 支持双机架扩展，可通过专用线缆为扩展机架供电。
7. 适配外部电源：可接 IC697 系列电源或第三方直流电源。
8. 提供电源状态监测与背板控制信号（如 ACFAIL、SYSRESET）。
9. 工业级设计，适应‑40℃~+70℃工作环境。
10. 具备过压、过流、短路保护，保障系统安全。
11. 重量约 0.57kg，尺寸紧凑，便于安装。
12. 已停产，市场以原装备件、翻新件为主。
13. 符合 CE、UL、RoHS 等国际安全与环保标准。
14. 接线需可靠接地，严禁带电插拔。
15. 是 90‑70 系统实现外部电源接入与多机架供电的关键适配组件。

IC697PWR720可编程控制器  英文资料：

Introduction to IC697PWR720 power adapter module

IC697PWR720 is a single slot power adapter module (PSA) specifically designed for GE Fanuc (now Emerson) Series 90-70 PLC systems. It is used to connect external power to the rack backplane, providing power to the CPU, I/O, and other modules.

Belonging to Series 90-70 PLC system, installed in the dedicated slot for rack power supply.

Core function: Transfer external power to the backplane, providing three outputs of+5VDC,+12VDC, and -12VDC.

Single slot design, occupying one rack slot.

Output specifications:+5VDC/18A,+12VDC/2A, -12VDC/1A.

It only requires a 5V bus on the backplane to provide a working current of 50mA.

Support dual rack expansion, which can be powered by dedicated cables for the expansion rack.

Compatible with external power supply: Can be connected to IC697 series power supply or third-party DC power supply.

Provide power status monitoring and backplane control signals (such as ACFAIL, SYSRESET).

Industrial grade design, suitable for working environments ranging from -40 ℃ to+70 ℃.

Equipped with overvoltage, overcurrent, and short-circuit protection to ensure system safety.

Weighing approximately 0.57kg, the size is compact and easy to install.

It has been discontinued, and the market mainly consists of original spare parts and refurbished parts.

Compliant with international safety and environmental standards such as CE, UL, RoHS, etc.

Wiring must be reliably grounded, and live plugging is strictly prohibited.

It is a key adaptive component for the 90-70 system to achieve external power access and multi rack power supply.

IC697PWR720, with its stable power conversion and expansion capabilities, has become the core component of flexible power supply solutions in Series 90-70 PLC systems and is widely used in industrial automation control scenarios.

IC697PWR720可编程控制器 产品展示
