IC670PBI001总线接口单元

IC670PBI001总线接口单元

1.产 品 资 料 介 绍：

1. 支持标准 Profibus‑DP 通信协议，可作为从站接入主流 PLC 系统
2. 通信速率范围 9.6Kbps~12Mbps，可根据现场需求灵活设置
3. 配备双 9 针 D‑Sub 接口，分别用于总线连接与手持编程器调试
4. 单模块最多可扩展连接 8 个 Field Control 系列 I/O 模块
5. 采用 18~30VDC 外部供电，典型使用 24VDC 工业电源
6. 可为后端 I/O 模块提供最大 1.4A 的逻辑总线电源
7. 通过 DIP 拨码开关设置总线地址，配置简单直观
8. 自带 PWR、RUN、OK 状态指示灯，方便查看运行与故障状态
9. 内置 1A 可更换慢熔保险丝，对电源输入进行过流保护
10. 总线与内部电路光电隔离，有效提升抗干扰能力
11. 具备非易失性参数存储，掉电后配置信息不丢失
12. 工作温度范围适应多数工业现场环境，稳定性强
13. 支持标准 DIN 导轨安装，结构紧凑便于机柜布局
14. 具备完善的诊断功能，可监测网络、I/O 及电源状态
15. 工业级高可靠设计，适合长时间连续运行

结尾

IC670PBI001总线接口单元 产品英文

IC670PBI001 is a Profibus DP bus interface unit of GE Fanuc Field Control series, mainly used to build distributed I/O networks and achieve stable and high-speed data transmission between controllers and field I/O modules.

Supports standard Profibus DP communication protocol and can be used as a slave to access mainstream PLC systems

The communication speed range is 9.6Kbps~12Mbps, which can be flexibly set according to on-site needs

Equipped with dual 9-pin D-Sub interfaces, used for bus connection and handheld programmer debugging respectively

A single module can expand and connect up to 8 Field Control series I/O modules

Using 18~30VDC external power supply, typically 24VDC industrial power supply is used

Can provide a maximum logic bus power supply of 1.4A for backend I/O modules

Set bus address through DIP dip switch, simple and intuitive configuration

Equipped with PWR, RUN, and OK status indicator lights for easy viewing of operational and fault status

Built in 1A replaceable slow melting fuse, providing overcurrent protection for power input

Bus and internal circuit are optically isolated, effectively enhancing anti-interference capability

Equipped with non-volatile parameter storage, configuration information will not be lost after power failure

The working temperature range is suitable for most industrial site environments and has strong stability

Supports standard DIN rail installation, compact structure for easy cabinet layout

Equipped with comprehensive diagnostic functions, capable of monitoring network, I/O, and power status

Industrial grade high reliability design, suitable for long-term continuous operation

ending

IC670PBI001, as the core interface component of distributed I/O systems, has flexible expansion and stable communication, and is a commonly used reliable bus unit in automation production lines and equipment control systems.

IC670PBI001总线接口单元  产品展示
