1.产 品 资 料 介 绍：
- 标准 VME 总线接口，适配 VME 工业机箱，即插即用
- 多轴伺服控制能力，支持高精度位置 / 速度 / 力矩控制
- 内置高性能处理器，运动算法响应快、实时性强
- 板载大容量缓存（64K×8-bit），数据处理效率高
- 24VDC 工业标准供电，功耗＜1W，低能耗设计
- 高速数据传输（最高 80MHz），满足高速同步控制需求
- 集成 NVRAM（8KB），参数断电保存、上电自动加载
- 多通道数字 I/O，可直接连接传感器、执行器
- 光电隔离信号设计，抗干扰、保护板卡与外设
- 工业级宽温（-40℃～+85℃），适配严苛车间环境
- 紧凑型板卡布局，标准 VME 尺寸，节省安装空间
- 表面贴装工艺 + 工业 PCB，抗震抗振、长期稳定
- 支持脉冲 / 模拟量指令输出，适配主流伺服驱动器
- 兼容 GE Mark VI 控制系统，适配冗余架构系统
- 适用于精密加工、自动化产线、机器人、高速定位场景
VME-MB-Z004伺服控制板 产品英文
VME-MB-Z004 servo control board, GE Fanuc VME bus high-performance motion control board.
Standard VME bus interface, compatible with VME industrial chassis, plug and play
Multi axis servo control capability, supporting high-precision position/velocity/torque control
Built in high-performance processor, fast motion algorithm response and strong real-time performance
Onboard large capacity cache (64K x 8-bit) with high data processing efficiency
24VDC industrial standard power supply, power consumption<1W, low-energy design
High speed data transmission (up to 80MHz) to meet the requirements of high-speed synchronous control
Integrated NVRAM (8KB), parameter power-off saving, automatic power on loading
Multi channel digital I/O, capable of directly connecting sensors and actuators
Optoelectronic isolation signal design, anti-interference, protection board and peripherals
Industrial grade wide temperature range (-40 ℃~+85 ℃), suitable for harsh workshop environments
Compact board layout, standard VME size, saving installation space
Surface mount technology+industrial PCB, earthquake and vibration resistance, long-term stability
Support pulse/analog command output, compatible with mainstream servo drivers
Compatible with GE Mark VI control system and compatible with redundant architecture systems
Suitable for precision machining, automated production lines, robots, and high-speed positioning scenarios
The VME-MB-Z004 servo control board has strong bus compatibility, high control accuracy, and good stability, making it the core board for industrial motion control.
VME-MB-Z004伺服控制板 产品展示
