1.产 品 资 料 介 绍：
- 核心配置 80196 微处理器 + 多片 EPROM，程序存储与运算能力强。
- 集成 21 个 4 位数码显示器 + 32 路状态 LED，参数与故障一目了然。
- 板载 - 24V 转 5V/3A 电源模块，自给供电，无需额外电源。
- 标准 Mark V 背板总线接口，与励磁系统主控无缝对接。
- 内置 16 键操作键盘，支持本地参数设置、校准与诊断。
- 支持 RS-232C 串口通信，与上位机或控制器数据交互。
- 专为发电机励磁控制设计，精准调节励磁电流与电压。
- 工业级 PCB 与三防涂层，抗粉尘油污，适配电站环境。
- 宽温 0–60℃工作，适配控制柜内温度波动工况。
- 紧凑卡式设计，标准机箱插槽直插，安装维护便捷。
- 具备过压 / 过流 / 过热保护，保障励磁系统安全稳定。
- 支持在线诊断与自检测，快速定位板卡与通道故障。
- 通道光电隔离设计，抗电磁干扰，避免信号串扰。
- 兼容 GE EX2000 全系列励磁系统，通用性强、互换性好。
- 广泛应用于火电、水电、燃气轮机发电机组励磁控制。
DS200UDSAG1ADE励磁标记板 产品英文
The GE DS200UDSAG1ADE excitation marking board is a dedicated display/keyboard interface board (excitation marking board) for the GE Mark V series EX2000 excitation system.
Core configuration: 80196 microprocessor+multiple EPROMs, with strong program storage and computing capabilities.
Integrate 21 4-digit digital displays and 32 status LEDs, making parameters and faults clear at a glance.
Onboard -24V to 5V/3A power module, self powered, no need for additional power supply.
Standard Mark V backplane bus interface, seamlessly integrated with the excitation system main control.
Built in 16 key operation keyboard, supporting local parameter setting, calibration, and diagnosis.
Support RS-232C serial communication for data exchange with the upper computer or controller.
Specially designed for generator excitation control, precise adjustment of excitation current and voltage.
Industrial grade PCB and three proof coating, resistant to dust and oil stains, suitable for power plant environments.
Working at a wide temperature range of 0-60 ℃, suitable for temperature fluctuations inside the control cabinet.
Compact card design, standard chassis slot direct insertion, easy installation and maintenance.
Equipped with overvoltage/overcurrent/overheating protection to ensure the safety and stability of the excitation system.
Support online diagnosis and self testing, quickly locate board and channel faults.
Channel optoelectronic isolation design, resistant to electromagnetic interference, avoiding signal crosstalk.
Compatible with the full range of GE EX2000 excitation systems, with strong universality and good interchangeability.
Widely used in excitation control of thermal power, hydropower, and gas turbine generator sets.
The GE DS200UDSAG1ADE excitation marking board has high integration, intuitive operation, stability and durability, and is the core board for local monitoring and operation of the excitation system of the generator set.
