GE 193X712AEG03 功率控制放大器卡
1.产 品 资 料 介 绍：
中文资料：
一、产品概述
193X712AEG03 是 GE（General Electric）公司 193X 系列中的一款功率控制放大器模块，广泛用于 GE 的Speedtronic、LCI 驱动系统或其他大型工业自动化平台，用于对电动机或功率器件进行精确控制和驱动信号放大。
二、功能特点
功率驱动信号输出：接收来自控制模块的低电平信号，放大后输出以驱动主功率器件，如 SCR、GTO、IGBT 等。
隔离放大功能：采用隔离技术，防止主电路对控制电路的干扰，提升系统抗扰性。
配合反馈控制系统：可接入电流、速度、电压等反馈信号，支持闭环调节功能。
过载保护设计：内置保护机制，防止信号短路或过载造成模块损坏。
插卡式设计：适配 GE 控制机柜，便于快速安装更换。
三、技术参数（典型）
工作电压：±15V DC（系统提供）
输入信号：模拟信号（如 ±10V）或 PWM 控制信号
输出驱动能力：典型输出电流可达 100～300mA
安装方式：GE 193X 标准插卡式结构
冷却方式：系统风冷或对流冷却
工作温度范围：-10°C 到 +60°C
外形尺寸：标准 193X 卡件尺寸（约 25 × 15 cm）
四、应用范围
GE LCI（Load Commutated Inverter）驱动系统
GE Mark II/IV/VI 控制系统中的功率调节环节
高压大功率电机启动与调速系统
风力发电、水电、燃气轮机控制系统
工业伺服控制系统、电源控制装置等
英文资料：
1、 Product Overview
193X712AEG03 is a power control amplifier module in GE's 193X series, widely used in GE's Speedtronic, LCI drive systems or other large industrial automation platforms for precise control and drive signal amplification of motors or power devices.
2、 Functional Features
Power drive signal output: Receive low-level signals from the control module, amplify them, and output them to drive main power devices such as SCR, GTO, IGBT, etc.
Isolation amplification function: using isolation technology to prevent interference from the main circuit to the control circuit and improve the system's immunity.
Cooperate with feedback control system: can access feedback signals such as current, speed, voltage, etc., and support closed-loop regulation function.
Overload protection design: Built in protection mechanism to prevent module damage caused by signal short circuit or overload.
Plug in card design: compatible with GE control cabinets for quick installation and replacement.
3、 Technical parameters (typical)
Working voltage: ± 15V DC (provided by the system)
Input signal: analog signal (such as ± 10V) or PWM control signal
Output driving capability: Typical output current can reach 100-300mA
Installation method: GE 193X standard plug-in card structure
Cooling method: System air cooling or convection cooling
Working temperature range: -10 ° C to+60 ° C
Dimensions: Standard 193X card size (approximately 25 × 15 cm)
4、 Application scope
GE LCI (Load Commutated Inverter) Drive System
Power regulation link in GE Mark II/IV/VI control system
High voltage and high-power motor starting and speed control system
Wind power generation, hydropower, and gas turbine control systems
Industrial servo control system, power control device, etc
2.产 品 展 示
