1.产 品 资 料 介 绍：
一、核心电气特点
- 额定功率：2840W（27.3V×40A），满足 KRC2 多轴伺服系统大电流需求。
- 输入电压：三相 400–480VAC，50/60Hz，适配工业电网。
- 输出规格：稳定 27.3VDC、40A，为机器人伺服驱动器提供精准母线电压。
- 转换效率：≥95%，低发热、高节能，适合长时间连续运行。
- 稳压精度：输出电压纹波小，动态响应快，适配机器人高速启停与加减速工况。
二、结构与安装特点
- 专用适配：库卡 KRC2 控制柜原装位设计，型号 00-109-802 为原厂备件号。
- 紧凑尺寸：约 9.5×10.8×6.3cm，重量仅 0.15kg，节省柜内空间。
- 强固结构：工业级金属外壳，抗震、抗电磁干扰，适应车间恶劣环境。
- 顶部安装：支持控制柜顶部均匀负载安装，最大承重 1000N。
- 即插即用：标准接口与 KRC2 系统直连，无需额外转接，维护便捷。
三、可靠性与保护特点
- 多重保护：内置过压、过流、短路、过温、输入欠压保护，自动故障切断。
- 高可靠设计：德国 MGV 原厂制造，100% 功能、高压与老化测试，MTBF 长。
- 宽温运行：工业级工作温度，满足 - 10℃～+55℃车间环境稳定工作。
- 抗干扰强：EMC 设计符合工业标准，抑制电网与伺服系统间电磁干扰。
- 长寿命：采用高品质元器件与 SMD 工艺，适合 24 小时不间断生产场景。
四、应用与认证
- 专属应用：库卡 KRC2 系列机器人控制器，覆盖焊接、搬运、装配等自动化产线。
- 合规认证：通过 TÜV、ISO 9001 等工业安全与质量认证，符合欧盟 CE 标准。
PH1003-2840 00-109-802电源模块 英文资料：
PH1003-2840 (00-109-802) is a 2840W high-power servo power module customized by German MGV for KUKA KRC2 robot controller, designed specifically for high dynamic and high reliability power supply scenarios of industrial robots.
1、 Core electrical characteristics
Rated power: 2840W (27.3V × 40A), meeting the high current requirements of KRC2 multi axis servo system.
Input voltage: three-phase 400-480VAC, 50/60Hz, suitable for industrial power grids.
Output specification: Stable 27.3VDC, 40A, providing precise bus voltage for robot servo drivers.
Conversion efficiency: ≥ 95%, low heat generation, high energy saving, suitable for long-term continuous operation.
Voltage stabilization accuracy: Small output voltage ripple, fast dynamic response, suitable for high-speed start stop and acceleration/deceleration working conditions of robots.
2、 Structure and installation characteristics
Special adaptation: KUKA KRC2 control cabinet original position design, model 00-109-802 is the original factory spare part number.
Compact size: approximately 9.5 × 10.8 × 6.3cm, weighing only 0.15kg, saving cabinet space.
Strong structure: Industrial grade metal shell, earthquake resistant, electromagnetic interference resistant, suitable for harsh workshop environments.
Top installation: Supports uniform load installation on the top of the control cabinet, with a maximum load capacity of 1000N.
Plug and play: The standard interface is directly connected to the KRC2 system without the need for additional adapters, making maintenance convenient.
3、 Reliability and Protection Characteristics
Multiple protection: Built in overvoltage, overcurrent, short circuit, over temperature, input undervoltage protection, automatic fault cut-off.
High reliability design: Made by MGV in Germany, with 100% functionality, high voltage and aging testing, and long MTBF.
Wide temperature operation: Industrial grade working temperature, meeting the stable operation of workshop environment from -10 ℃ to+55 ℃.
Strong anti-interference: The EMC design meets industrial standards and suppresses electromagnetic interference between the power grid and servo system.
Long lifespan: Using high-quality components and SMD technology, suitable for 24-hour uninterrupted production scenarios.
4、 Application and Authentication
Exclusive application: KUKA KRC2 series robot controller, covering automated production lines such as welding, handling, and assembly.
Compliance certification: Passed industrial safety and quality certifications such as T Ü V and ISO 9001, in compliance with EU CE standards.
