1.产 品 资 料 介 绍：
- 输出规格 27.3VDC、20A，额定功率约 546W，满足 KRC2 中低负载轴组供电。
- 三相交流输入 380–480VAC，50/60Hz，兼容工业标准电网。
- 输出电压可在 23.5–28.5V 范围内微调，适配不同工况需求。
- 转换效率≥94%，低发热、低损耗，适合 24 小时连续运行。
- 输出纹波小，稳压精度高，动态响应快，适配机器人频繁启停。
- 库卡 KRC2 控制柜专用原装位设计，备件号 00-108-032。
- 工业级紧凑结构，尺寸匹配原装安装位置，无需改造。
- 金属外壳加固，抗震、抗粉尘，适应恶劣车间环境。
- 标准接口定义与原厂一致，直插直用，更换维护简单。
- 高效自然风冷散热，长时间满载工作温度稳定。
- 内置过压、过流、短路、过温、输入欠压多重保护。
- 输出防反接保护，降低安装接线失误损坏风险。
- EMC 抗干扰设计，符合工业电磁兼容标准，不干扰伺服系统。
- 工作温度范围 - 10℃～+55℃，满足工业现场环境。
- 采用长寿命元器件，100% 老化测试，可靠性高。
- 通过 CE、TÜV 等安全认证，符合欧盟工业设备规范。
- 主要用于库卡 KRC2 系列机器人，适用于搬运、装配、焊接等自动化产线。
PH603-2820 00-108-032机器人电源模块 英文资料：
PH603-2820 (00-108-032) is a 27.3V/20A DC servo power module produced by MGV in Germany and used in the KUKA KRC2 robot control cabinet. It is designed specifically for low to medium power robot systems.
The output specification is 27.3VDC, 20A, with a rated power of approximately 546W, meeting the power supply requirements for KRC2 medium and low load shaft groups.
Three phase AC input 380-480VAC, 50/60Hz, compatible with industrial standard power grids.
The output voltage can be fine tuned within the range of 23.5-28.5V to adapt to different operating conditions.
Conversion efficiency ≥ 94%, low heat generation, low loss, suitable for 24-hour continuous operation.
Small output ripple, high voltage regulation accuracy, fast dynamic response, suitable for frequent start stop of robots.
KUKA KRC2 control cabinet is designed with a dedicated original position, spare part number 00-108-032.
Industrial grade compact structure, size matching original installation position, no need for modification.
Metal shell reinforcement, earthquake resistance, dust resistance, suitable for harsh workshop environments.
The standard interface definition is consistent with the original factory, directly inserted and used, and easy to ｒｅｐｌａｃｅ and maintain.
Efficient natural air cooling for heat dissipation, stable temperature during long-term full load operation.
Built in multiple protections for overvoltage, overcurrent, short circuit, over temperature, and input undervoltage.
Output anti reverse protection to reduce the risk of damage caused by installation and wiring errors.
EMC anti-interference design, compliant with industrial electromagnetic compatibility standards, does not interfere with servo systems.
The working temperature range is -10 ℃ to+55 ℃, which meets the requirements of industrial site environment.
Using long-life components, 100% aging testing, high reliability.
Passed CE, T Ü V and other safety certifications, in compliance with EU industrial equipment standards.
Mainly used for KUKA KRC2 series robots, suitable for automated production lines such as handling, assembly, and welding.
PH603-2820 00-108-032机器人电源模块 产品展示
