1.产 品 资 料 介 绍：
- 适配系统：专为 KUKA KRC2、KRC2 ED05 控制柜设计，与 MFC3、CI3 等控制模块兼容。
- 通道配置：标配 16 路数字输入（DI）+16 路数字输出（DO），共 32 路基础 I/O 通道。
- 输入类型：24V DC NPN/PNP 兼容，支持干接点与有源传感器信号接入。
- 输出类型：24V DC 晶体管输出，单通道最大驱动电流 0.5A，适配电磁阀、继电器等负载。
- 信号隔离：输入 / 输出通道光电隔离，抗干扰能力强，保护控制器免受外部浪涌冲击。
- 状态指示：每路 DI/DO 均配独立 LED 指示灯，实时显示信号通断，便于快速诊断。
- 供电方式：由控制柜 24V DC 辅助电源供电，无需额外独立电源，简化系统布线。
- 地址配置：支持硬件地址拨码或软件配置，可与其他 I/O 板级联扩展。
- 通信接口：通过 DSE-IBS 内部总线与控制器 CPU 通信，信号传输实时性高。
- 接线方式：标准端子排接线，通道编号清晰，支持快速现场布线与维护。
- 工业设计：金属外壳加固，抗震、抗粉尘，适应车间恶劣环境。
- 宽温运行：工作温度 - 10℃～+55℃，满足工业现场环境要求。
- 保护功能：内置过流、短路保护，防止外部故障损坏模块。
- 即插即用：原装位设计，接口定义与原厂一致，更换维护便捷。
- 应用场景：用于搬运、装配、焊接等自动化产线，实现机器人与外围设备信号交互。
- 合规认证：通过 CE、TÜV 等工业安全认证，符合欧盟标准。
00-108-473输入输出板单元 英文资料：
00-108-473 is a digital input/output (I/O) board unit dedicated to the KUKA KRC2/KRC2 ED05 robot control cabinet, used for signal interaction between the robot and external sensors and actuators.
Adaptation System: Designed specifically for KUKA KRC2 and KRC2 ED05 control cabinets, compatible with control modules such as MFC3 and CI3.
Channel configuration: Standard configuration includes 16 digital inputs (DI) and 16 digital outputs (DO), totaling 32 basic I/O channels.
Input type: 24V DC NPN/PNP compatible, supports dry contact and active sensor signal access.
Output type: 24V DC transistor output, maximum single channel driving current of 0.5A, suitable for loads such as solenoid valves and relays.
Signal isolation: The input/output channels are optically isolated, with strong anti-interference ability, protecting the controller from external surge impact.
Status indication: Each DI/DO is equipped with an independent LED indicator light, which displays the signal on/off in real time for quick diagnosis.
Power supply method: Powered by a 24V DC auxiliary power supply from the control cabinet, no additional independent power supply is required, simplifying system wiring.
Address configuration: Supports hardware address dialing or software configuration, and can be cascaded and expanded with other I/O boards.
Communication interface: Communicate with the controller CPU through the DSE-IBS internal bus, with high real-time signal transmission.
Wiring method: Standard terminal block wiring, clear channel numbering, supports fast on-site wiring and maintenance.
Industrial design: metal shell reinforcement, earthquake resistance, dust resistance, suitable for harsh workshop environments.
Wide temperature operation: The working temperature ranges from -10 ℃ to+55 ℃, meeting the environmental requirements of industrial sites.
Protection function: Built in overcurrent and short-circuit protection to prevent external faults from damaging the module.
Plug and play: original design, interface definition consistent with the original factory, easy replacement and maintenance.
Application scenario: Used for automated production lines such as handling, assembly, welding, etc., to achieve signal interaction between robots and peripheral devices.
Compliance certification: Passed industrial safety certifications such as CE and T Ü V, in compliance with EU standards.
00-108-473输入输出板单元 产品展示
