Motorola MVME-5500 CPU模块

Motorola  MVME-5500 CPU模块

1.产 品 资 料 介 绍：

核心规格对比

功能特点

• 高性能计算：PowerPC 74xx 配合 AltiVec，适合实时数据处理与算法运算。
• 灵活扩展：双 PCI 与双 PMC 可扩展通信、存储、专用 I/O。
• 高可靠性：工业级设计，抗振动、宽温、EMC 兼容，适合恶劣环境。
• 多系统支持：主流实时与通用嵌入式操作系统均可运行。

应用场景

• 工业自动化：运动控制、逻辑运算、数据采集。
• 电力与能源：电网监控、变电站自动化。
• 国防与航空电子：雷达、导航、舰载控制系统。
• 医疗设备：成像与控制。
• 交通与通信：交通监控、基站控制。

选型建议

1. 明确处理器型号（7455/7457/7475）及内存容量，不同批次可能存在差异。
2. 确认所需扩展：是否需要双千兆网、特定 PMC 接口（如 CAN、光纤）。
3. 关注工作温度与功耗，极端环境需选择宽温版本。
4. 确认操作系统支持及驱动可用性，尤其是 Linux 或 Windows XP Embedded。
5. 注意向后兼容性，便于旧系统升级。

Motorola MVME-5500 CPU模块 英文资料：

The Motorola MVME-5500 is a high-performance CPU module based on VMEbus, using PowerPC 74xx series processors, aimed at applications that require high reliability real-time computing in industrial automation, defense, healthcare, transportation, and other fields.

Comparison of core specifications

Typical parameter description of the project

Processor PowerPC 7455/7457/7475 with a clock speed of 1 GHz and AltiVec vector acceleration

Memory 1-2 GB DDR SDRAM partially supports ECC, up to 133 MHz

Onboard 8-40 MB Flash, expandable CompactFlash, SCSI, SATA

Bus interface VME64 master/slave A32/D64/BLT64, compatible with Universe II

Expand dual 64 bit PCI at 33/66 MHz

The dual PMC slots can be expanded to 4 PMC spans

Network 10/100/1000Base-T+10/100Base-T dual independent Ethernet

Other I/O 2 x serial ports, parallel ports (partially), USB (partially) can be expanded through PMC for more

Working temperature -40 ℃~+85 ℃ Industrial wide temperature range

Size approximately 223 × 168 × 44 mm 6U VME single board

Power consumption ≤ 20 W (+5 V), typical 15-20 W

The operating systems VxWorks, Lynx OS, pSOS, and embedded Linux partially support Windows XP Embedded

Features

High performance computing: PowerPC 74xx combined with AltiVec is suitable for real-time data processing and algorithm computation.

Flexible expansion: Dual PCI and dual PMC can expand communication, storage, and dedicated I/O.

High reliability: Industrial grade design, vibration resistance, wide temperature range, EMC compatibility, suitable for harsh environments.

Multi system support: Both mainstream real-time and general-purpose embedded operating systems can run.

Application scenarios

Industrial automation: motion control, logical operation, data acquisition.

Electricity and Energy: Grid Monitoring, Substation Automation.

Defense and Aviation Electronics: Radar, Navigation, Shipborne Control Systems.

Medical equipment: imaging and control.

Transportation and Communication: Traffic Monitoring, Base Station Control.

Selection suggestions

Please specify the processor model (7455/7457/7475) and memory capacity, as there may be differences between different batches.

Confirm the required expansion: whether dual gigabit network and specific PMC interfaces (such as CAN, fiber optic) are needed.

Pay attention to working temperature and power consumption, and choose the wide temperature version for extreme environments.

Confirm operating system support and driver availability, especially for Linux or Windows XP Embedded.

Pay attention to backward compatibility to facilitate the upgrade of old systems.

Motorola MVME-5500 CPU模块  产      品      展      示

 产品视频
