Motorola MVME025系统控制器模块

Motorola  MVME025系统控制器模块

1.产 品 资 料 介 绍：

核心规格对比

功能特点

• 高性能计算：PowerPC 74xx 配合 AltiVec，适合实时数据处理与算法运算。
• 灵活扩展：双 PCI 与双 PMC 可扩展通信、存储、专用 I/O。
• 高可靠性：工业级设计，抗振动、宽温、EMC 兼容，适合恶劣环境。
• 多系统支持：主流实时与通用嵌入式操作系统均可运行。

应用场景

• 工业自动化：运动控制、逻辑运算、数据采集。
• 电力与能源：电网监控、变电站自动化。
• 国防与航空电子：雷达、导航、舰载控制系统。
• 医疗设备：成像与控制。
• 交通与通信：交通监控、基站控制。

Motorola MVME025系统控制器模块 英文资料：

The Motorola MVME-5500 is a high-performance CPU module based on VMEbus, using PowerPC 74xx series processors, aimed at applications that require high reliability real-time computing in industrial automation, defense, healthcare, transportation, and other fields.

Comparison of core specifications

Typical parameter description of the project

Processor PowerPC 7455/7457/7475 with a clock speed of 1 GHz and AltiVec vector acceleration

Memory 1-2 GB DDR SDRAM partially supports ECC, up to 133 MHz

Onboard 8-40 MB Flash, expandable CompactFlash, SCSI, SATA

Bus interface VME64 master/slave A32/D64/BLT64, compatible with Universe II

Expand dual 64 bit PCI at 33/66 MHz

The dual PMC slots can be expanded to 4 PMC spans

Network 10/100/1000Base-T+10/100Base-T dual independent Ethernet

Other I/O 2 x serial ports, parallel ports (partially), USB (partially) can be expanded through PMC for more

Working temperature -40 ℃~+85 ℃ Industrial wide temperature range

Size approximately 223 × 168 × 44 mm 6U VME single board

Power consumption ≤ 20 W (+5 V), typical 15-20 W

The operating systems VxWorks, Lynx OS, pSOS, and embedded Linux partially support Windows XP Embedded

Features

High performance computing: PowerPC 74xx combined with AltiVec is suitable for real-time data processing and algorithm computation.

Flexible expansion: Dual PCI and dual PMC can expand communication, storage, and dedicated I/O.

High reliability: Industrial grade design, vibration resistance, wide temperature range, EMC compatibility, suitable for harsh environments.

Multi system support: Both mainstream real-time and general-purpose embedded operating systems can run.

Application scenarios

Industrial automation: motion control, logical operation, data acquisition.

Electricity and Energy: Grid Monitoring, Substation Automation.

Defense and Aviation Electronics: Radar, Navigation, Shipborne Control Systems.

Medical equipment: imaging and control.

Transportation and Communication: Traffic Monitoring, Base Station Control.

Motorola MVME025系统控制器模块  产      品      展      示
