GIDDINGS & LEWIS DSM175伺服驱动器

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS DSM175 伺服驱动器产品详解

一、产品概述：工业自动化的核心驱动单元

二、技术参数：适配多样化工业场景

核心性能参数

• 额定电流：支持大功率伺服电机驱动，输出电流范围宽泛，能够适配不同功率等级的电机，满足从中小功率到较大功率设备的驱动需求。
• 电源输入：采用三相 AC 工业电源，常见电压范围为 380V~480V，符合工业用电标准，便于接入各类工业供电系统。
• 控制模式：具备位置控制、速度控制、扭矩控制三种核心模式，可根据实际应用场景灵活切换。例如，在精密定位场景中选用位置控制模式，在恒速运行场景中采用速度控制模式，在负载恒定的场合则可使用扭矩控制模式。
• 反馈类型：兼容编码器、解析器等多种闭环反馈装置，通过实时接收反馈信号，实现对电机运行状态的精准监控与调节，保证控制精度。

保护与接口特性

• 保护功能：内置全面的保护机制，包括过压、欠压保护（防止电源电压异常损坏设备）、过流保护（避免电机或驱动器因电流过大烧毁）、过热保护（当设备温度过高时自动停机）、短路保护（应对电路短路故障）及反馈异常保护（确保反馈信号异常时系统安全），大幅提升设备运行的安全性与可靠性。
• 接口：配备多种通讯总线接口，可便捷地与上位机、PLC 等控制系统连接，实现数据的实时交互与指令传输，融入复杂的工业自动化网络。

英文资料：

GIDINGS&LEWIS DSM175 servo drive product detailed explanation

1、 Product Overview: The Core Driver Unit of Industrial Automation

GIDINGS&LEWIS DSM175 servo drive, as a high-performance drive unit designed specifically for industrial automation and motion control systems, is a key bridge connecting control systems and servo motors. It works in conjunction with feedback devices such as servo motors, encoders, and parsers to build a complete closed-loop control system, accurately regulating the three core parameters of speed, position, and torque.

As an important member of the G&L brand DSM series, this driver has become a core driver product in high-end CNC machine tools and automation equipment due to its excellent performance. The original intention of its design is to meet the stringent requirements of high dynamic response and high-precision machining, providing a solid guarantee for precision motion control in industrial production.

2、 Technical parameters: Suitable for diverse industrial scenarios

Core performance parameters

Rated current: Supports high-power servo motor drive, with a wide range of output currents, able to adapt to motors of different power levels, and meet the driving needs of devices ranging from medium to high power.

Power input: Adopting three-phase AC industrial power supply, the common voltage range is 380V~480V, which meets industrial power standards and is easy to connect to various industrial power supply systems.

Control mode: It has three core modes: position control, speed control, and torque control, which can be flexibly switched according to actual application scenarios. For example, in precision positioning scenarios, position control mode is used, in constant speed operation scenarios, speed control mode is used, and in situations where the load is constant, torque control mode can be used.

Feedback type: Compatible with various closed-loop feedback devices such as encoders and parsers, it achieves precise monitoring and adjustment of motor operation status by receiving feedback signals in real time, ensuring control accuracy.

Protection and Interface Characteristics

Protection function: Built in comprehensive protection mechanisms, including overvoltage and undervoltage protection (to prevent abnormal power supply voltage from damaging equipment), overcurrent protection (to prevent motors or drivers from burning out due to excessive current), overheating protection (to automatically shut down when the equipment temperature is too high), short circuit protection (to deal with circuit short circuit faults), and feedback abnormality protection (to ensure system safety in case of abnormal feedback signals), greatly improving the safety and reliability of equipment operation.

Interface: Equipped with multiple communication bus interfaces, it can easily connect with control systems such as upper computer and PLC, achieve real-time data interaction and instruction transmission, and integrate into complex industrial automation networks.

2.产      品      展      示
