GIDINGS&LEWIS M.1301.9684车床工具柱

1.产 品 资 料 介 绍：

GIDDINGS & LEWIS M.1301.9684 车床工具柱解析

一、产品概述

二、技术参数（典型特性）

• 产品型号：M.1301.9684
• 部件类型：专为车床设计的工具柱，聚焦刀具支撑与定位功能
• 功能定位：核心作用是支撑车床刀具并精准定位，为加工操作提供稳定基础，确保刀具在加工过程中位置不偏移
• 材质选择：采用高强度钢或合金材料（如铬钼合金钢），经热处理强化工艺提升硬度与韧性，既保证长期使用的耐磨性（减少刀具定位面磨损），又具备出色的刚性（抵御切削力导致的形变）
• 安装方式：兼容数控车床标准安装接口（如 T 型槽、法兰定位结构），无需对车床进行改造即可直接替换旧工具柱，安装后调试便捷，大幅缩短设备停机换件时间
• 精度特性：刀具定位精度高，定位误差通常控制在 0.005mm 以内，且重复定位精度稳定，能适应高速加工（如主轴转速≥3000r/min）场景下的动态稳定性需求，避免高速运转带来的刀具震颤
• 承载能力：具备高负载承受能力，可稳定承载刀具切削过程中产生的径向、轴向切削力，以及工件旋转带来的附加负载，最大承载切削力适配中重型车削加工需求
• 适配性能：兼容性强，可搭配各类数控车床刀具系统（如刀塔、刀架式刀具组），支持外圆车刀、内孔镗刀、螺纹刀等多种刀具安装，满足不同加工工艺需求

英文资料：

GIDINGS&LEWIS M.1301.9684 lathe tool column analysis

1、 Product Overview

GIDINGS&LEWIS M.1301.9684 lathe tool column is a core mechanical support component in CNC lathes and automated machining equipment, responsible for the key function of "tool support - precise positioning". It provides reliable support and precise position fixation for machining tools through stable structural design, ensuring that the tools maintain a stable posture during turning, boring, and other machining of workpieces; Simultaneously integrating high-strength materials and precision machining processes, it can resist the impact and vibration caused by high-speed rotation and high cutting loads, avoid machining errors caused by tool displacement, and perfectly adapt to the dual requirements of "stability" and "accuracy" in precision machining. It is the core mechanical component that ensures efficient and precise production of CNC lathes.

2、 Technical parameters (typical characteristics)

Product model: M.1301.9684

Component type: Tool column designed specifically for lathes, focusing on tool support and positioning functions

Functional positioning: The core function is to support lathe tools and accurately position them, providing a stable foundation for machining operations and ensuring that the position of the tools does not shift during the machining process

Material selection: High strength steel or alloy materials (such as chromium molybdenum alloy steel) are used, which are strengthened by heat treatment to enhance hardness and toughness. This ensures long-term wear resistance (reducing tool positioning surface wear) and excellent rigidity (resisting deformation caused by cutting forces)

Installation method: compatible with the standard installation interface of CNC lathe (such as T-groove and flange positioning structure), it can directly ｒｅｐｌａｃｅ the old tool post without modifying the lathe, and it is convenient to debug after installation, greatly reducing the time for equipment shutdown and replacement

Accuracy characteristics: The tool has high positioning accuracy, with positioning error usually controlled within 0.005mm, and stable repeat positioning accuracy, which can adapt to the dynamic stability requirements of high-speed machining (such as spindle speed ≥ 3000r/min) scenarios and avoid tool vibration caused by high-speed operation

Load bearing capacity: With high load bearing capacity, it can stably bear the radial and axial cutting forces generated during the cutting process of the tool, as well as the additional load caused by the rotation of the workpiece. The maximum load-bearing cutting force is suitable for medium and heavy-duty turning processing needs

Adaptability: Strong compatibility, can be matched with various CNC lathe tool systems (such as turret and tool holder), supports the installation of various tools such as external turning tools, internal boring tools, threading tools, etc., to meet different processing requirements

2.产      品      展      示
