GIDDINGS & LEWIS M.1301.2073 图形触摸屏解析

一、产品概述

二、技术参数（典型特性）

• 产品型号：M.1301.2073
• 设备类型：工业级图形触摸屏（HMI），聚焦工业场景人机交互需求
• 显示特性：采用高分辨率彩色液晶显示屏（分辨率通常≥1280×720，具体视配置而定），色彩还原度高、画面清晰度强，可清晰呈现设备运行曲线、工艺流程图、报警提示等复杂信息，即使在工业现场强光环境下，仍能保证画面可视性（屏幕亮度≥500cd/㎡）
• 触控方式：支持电阻式或电容式触控（根据系统配置选择），电阻式触控适应油污、粉尘等恶劣操作环境，电容式触控支持多点触控（如双指缩放画面、滑动切换界面），触控响应速度快（≤100ms），操作流畅无卡顿，同时具备防误触设计（可设置触摸灵敏度阈值）
• 接口配置：配备丰富的工业通信接口，包括以太网接口（支持 Modbus TCP、Profinet 等协议，实现与控制器、上位系统的数据交互）、串口（如 RS232/RS485，对接 PLC、传感器等设备）、USB 接口（用于程序上传 / 下载、数据备份、外接鼠标键盘），接口兼容性强，无需额外转换模块即可对接多数工业设备
• 操作系统 / 固件：搭载工业级专用操作系统（如嵌入式 Linux），稳定性高、抗崩溃能力强；支持自定义界面设计（可通过专用软件拖拽控件、编辑画面布局），并提供丰富的预设控件（如按钮、指示灯、数值显示框、趋势图），便于根据不同工业场景定制专属操作界面

英文资料：

GIDINGS&LEWIS M.1301.2073 Graphic Touch Screen Analysis

1、 Product Overview

GIDINGS&LEWIS M.1301.2073 graphic touch screen is a core human-machine interface (HMI) device designed specifically for industrial automation systems and CNC machine tools, responsible for the key functions of "operation interaction status monitoring process management". It uses an intuitive graphical interface as a carrier, breaking the complex button operation mode of traditional industrial equipment. Through high-resolution display, real-time device operation data is presented, and with convenient touch operation, operators can quickly view device status (such as motor speed, machining progress), flexibly adjust process parameters (such as cutting speed, temperature threshold), and efficiently manage production processes (such as starting/pausing machining programs). This touch screen combines visual advantages and operational convenience, serving as a "communication bridge" between operators and industrial equipment, as well as a core component for improving system operation efficiency and reducing the risk of misoperation. It perfectly adapts to the dual requirements of "intuitive interaction" and "precise control" in industrial scenarios.

2、 Technical parameters (typical characteristics)

Product model: M.1301.2073

Equipment type: Industrial grade graphical touch screen (HMI), focusing on human-machine interaction needs in industrial scenarios

Display characteristics: Adopting a high-resolution color LCD display screen (usually with a resolution of ≥ 1280 × 720, depending on the configuration), with high color reproduction and strong image clarity, it can clearly present complex information such as equipment operation curves, process flow diagrams, alarm prompts, etc. Even in strong light environments in industrial sites, it can still ensure image visibility (screen brightness ≥ 500cd/㎡)

Touch mode: Supports resistive or capacitive touch (selected according to system configuration), resistive touch is suitable for harsh operating environments such as oil stains and dust, capacitive touch supports multi touch (such as dual finger zoom screen, sliding switch interface), fast touch response speed (≤ 100ms), smooth operation without stuttering, and also has anti misoperation design (touch sensitivity threshold can be set)

Interface configuration: Equipped with rich industrial communication interfaces, including Ethernet interfaces (supporting Modbus TCP, Profinet and other protocols to achieve data exchange with controllers and upper systems), serial ports (such as RS232/RS485, for docking with PLC, sensors and other devices), USB interfaces (for program upload/download, data backup, external mouse and keyboard), strong interface compatibility, and can dock with most industrial devices without the need for additional conversion modules

Operating system/firmware: equipped with industrial grade dedicated operating systems (such as embedded Linux), high stability and strong anti crash ability; Support custom interface design (can drag and ｄｒｏｐ controls through dedicated software, edit screen layout), and provide rich preset controls (such as buttons, indicator lights, numerical display boxes, trend charts), making it easy to customize exclusive operating interfaces according to different industrial scenarios
