GIDINGS&LEWIS M-1017-6242控制器模块

 GIDINGS&LEWIS  M-1017-6242控制器模块

1.产 品 资 料 介 绍：

一、产品概述

二、技术特性

1. 中央逻辑处理：能解读控制指令，完成逻辑运算，进而实现设备运动控制和各设备间的协调，让整个系统按要求运行。
2. 实时控制能力：对输入的信号反应快，能精准控制设备运动，保证自动化操作的准确性。
3. 模块化设计：可以直接装在 PiC900 系统机架上，后续要扩展系统功能或者维护，都很方便。
4. 接口兼容性：和 G&L 系列的 CPU、I/O 模块、伺服驱动器、编码器都能无缝连接，不用额外适配。
5. 工业可靠性：不怕电磁干扰和振动，能在恶劣环境里长时间稳定工作，适合工业现场使用。

三、应用领域

1. 数控机床：接收并处理机床的运动指令，控制多个轴的运动，还能规划刀具的移动路径。同时，能协调冷却设备、液压装置、夹具等一起动作，保证机床正常加工。
2. 自动化生产线：在装配、搬运、分拣、包装这些环节中，它能收集传感器的数据，再控制执行器干活，让整条生产线实现自动化运行，不用太多人工干预。
3. 工业过程控制：用在冶金、化工、能源等行业的生产流程里，控制阀门开关、电机运转、泵站工作，让生产过程自动进行，减少人为操作误差。
4. 机器人与运动系统：能协调机器人各个关节的动作，规划运动轨迹，让机器人运动更精准、更稳定，提升作业效果。
5. 分布式控制系统：作为中间控制模块，协调多个 I/O 模块和伺服驱动器，实现分散式的工业控制，适应大型工业场景的需求。

英文资料：

1、 Product Overview

GIDINGS&LEWIS M-1017-6242 is the core controller module in the PiC900 series, mainly used in industrial automation systems. Its core job is to perform logical operations, control device movements, and coordinate different devices to work together. In practical use, it will be combined with CPU, I/O modules, servo drives, and encoders to form a complete distributed control system that meets the automation needs of industrial production.

2、 Technical characteristics

Central logic processing: capable of interpreting control instructions, completing logical operations, and achieving device motion control and coordination between devices, enabling the entire system to operate as required.

Real time control capability: responds quickly to input signals, accurately controls equipment movement, and ensures the accuracy of automated operations.

Modular design: It can be directly installed on the PiC900 system rack, making it convenient for expanding system functions or maintenance in the future.

Interface compatibility: It can seamlessly connect with G&L series CPUs, I/O modules, servo drives, and encoders without the need for additional adaptation.

Industrial reliability: Not afraid of electromagnetic interference and vibration, able to work stably for a long time in harsh environments, suitable for industrial site use.

3、 Application Fields

Numerical Control Machine Tool: Receive and process motion commands from the machine tool, control the movement of multiple axes, and plan the path of tool movement. At the same time, it can coordinate the action of cooling equipment, hydraulic devices, fixtures, etc. to ensure the normal processing of the machine tool.

Automated production line: In the processes of assembly, handling, sorting, and packaging, it can collect sensor data and control actuators to work, enabling the entire production line to operate automatically without too much manual intervention.

Industrial process control: used in the production processes of metallurgy, chemical industry, energy and other industries to control valve opening and closing, motor operation, and pump station work, making the production process automatic and reducing human operation errors.

Robots and motion systems: capable of coordinating the movements of various joints of robots, planning motion trajectories, making robot movements more precise and stable, and improving work efficiency.

Distributed Control System: As an intermediate control module, it coordinates multiple I/O modules and servo drives to achieve decentralized industrial control and adapt to the needs of large-scale industrial scenarios.

 2.产      品      展      示
