GIDINGS&LEWIS  572-03551-02输入输出模块

1.产 品 资 料 介 绍：

Giddings & Lewis 572-03551-02 输入输出模块介绍

一、产品概述

二、产品应用领域

（一）数控机床

1. 信号采集精准化：模块可接收来自多种关键设备的信号 —— 通过编码器采集主轴、进给轴的位置与速度反馈信号，为机床的精准定位提供数据支撑；接收限位开关信号（如行程极限、刀具到位信号），防止机床运动超程或刀具安装异常；同时，采集温度传感器、振动传感器信号，实时监控主轴、导轨等关键部件的运行状态，避免因过热、过度振动导致的设备损坏或加工误差。
2. 执行控制精细化：根据 PiC 控制器的指令，模块向执行器发送精准控制信号 —— 驱动夹具电磁阀实现工件的夹紧与松开，确保加工过程中工件稳固；控制润滑泵的启停与供油量，为机床运动部件提供持续润滑，减少机械磨损；同时，驱动冷却液阀、排屑装置等执行元件，根据加工进度动态调整工作状态（如切削时开启冷却液，加工完成后启动排屑），保障数控机床加工流程的顺畅与高效。此外，模块还支持机床主轴和进给轴的精确控制，通过与伺服系统协同，实现主轴转速的无级调节、进给轴的微米级定位，满足精密零件加工对精度的严苛要求。

英文资料：

Introduction to Giddings&Lewis 572-03551-02 Input/Output Modules

1、 Product Overview

The Giddings&Lewis 572-03551-02 input/output module is the core bidirectional interface module in the PiC series control system that enables "external signal interaction" and "control instruction execution". It can be regarded as the "signal bridge" between the control system, machine tools, and automation equipment. Its core functions include bidirectional signal processing: on the one hand, it accurately receives digital or analog signals output by external sensors (such as temperature sensors, encoders, limit switches), and after internal signal conditioning and conversion, transmits them to the PiC controller to provide real-time operating data for system decision-making; On the other hand, receiving control instructions issued by the controller, converting them into driving signals that can be recognized by the executing devices (such as solenoid valves, motors, indicator lights), driving the equipment to complete preset actions, and achieving precise control of external equipment by the control system.

In the field of industrial automation, this module is a key link connecting the "perception layer" (sensors) and the "execution layer" (actuators), widely used in scenarios such as CNC machine tools and automated production lines, providing essential signal interaction support for precise control, real-time monitoring, and efficient collaboration of the system.

2、 Product application areas

（1） CNC machine tool

In the control system of CNC machine tools, the input-output module is the core component that ensures machining accuracy and equipment safety, undertaking the dual tasks of signal acquisition and action control.

Accurate signal acquisition: The module can receive signals from various key devices - by using encoders to collect feedback signals on the position and speed of the spindle and feed axis, providing data support for the precise positioning of the machine tool; Receive limit switch signals (such as travel limit and tool in place signals) to prevent the machine tool from exceeding its travel limit or abnormal tool installation; At the same time, temperature sensor and vibration sensor signals are collected to monitor the operating status of key components such as the spindle and guide rail in real time, avoiding equipment damage or processing errors caused by overheating and excessive vibration.

Fine control execution: According to the instructions of the PiC controller, the module sends precise control signals to the actuator - driving the fixture solenoid valve to clamp and release the workpiece, ensuring the stability of the workpiece during the machining process; Control the start stop and oil supply of the lubrication pump to provide continuous lubrication for the moving parts of the machine tool and reduce mechanical wear; At the same time, the actuator components such as the coolant valve and chip removal device are driven to dynamically adjust the working state according to the machining progress (such as turning on the coolant during cutting and starting chip removal after machining is completed), ensuring the smooth and efficient machining process of the CNC machine tool. In addition, the module also supports precise control of the machine tool spindle and feed axis. By collaborating with the servo system, it achieves stepless adjustment of spindle speed and micrometer level positioning of the feed axis, meeting the strict requirements for precision machining of parts.
