1.产 品 资 料 介 绍：

核心规格

功能与优势

• 高安全设计：双回路冗余联锁，异常即停机，防止误操作。
• 长寿命稳定：镀金触点 + 工业级外壳，适应频繁插拔与恶劣环境。
• 防护可靠：IP67 防尘防水，可用于真空、化学环境。
• 信号稳定：低接触电阻与高绝缘，减少误告警。
• 安装便捷：标准接口，可快速替换，支持现场定制回路。

安装与维护要点

1. 安装
   • 确保联锁执行机构与连接器位置精准匹配。
   • 按回路定义接线，常闭用于安全回路，常开用于状态指示。
   • 固定牢固，避免松动影响检测。
2. 调试
   • 手动开合联锁机构，确认触点动作与主控系统信号一致。
   • 测量接触电阻与绝缘电阻，确保在规格范围内。
3. 维护
   • 定期清洁触点与外壳，防止灰尘、水汽或化学腐蚀。
   • 每 6–12 个月检查机械磨损，必要时更换触点或整机。
   • 保存校准与更换记录，便于追溯。

AMAT Applied Materials  0021-21840联锁连接器 英文资料：

AMAT 0021-21840 is a high-performance connector designed by Applied Materials for semiconductor equipment safety interlock systems. It is used to detect the position status when opening and closing chamber doors, gas cabinets, vacuum components, etc., and trigger shutdown protection in case of abnormalities, ensuring the safety of operators and equipment.

Core specifications

Project specifications/characteristics remarks

Type interlock detection connector (normally closed/normally open contacts), dry contacts or photoelectric type optional

Contact form 2NO+2NC (typical) customizable single/double circuit

Rated current/voltage 5 A/240 VAC (resistive) industrial load capacity

Contact resistance ≤ 50 m Ω (initial) gold-plated contacts, resistant to oxidation

Insulation resistance ≥ 1000 M Ω (500 VDC), high insulation ensures safety

Mechanical lifespan ≥ 1 million insertions, removals, or threaded connections

Protection level IP67 (plugged in state) dustproof and waterproof

Suitable for a wide temperature environment with a working temperature range of -40 to+85 ℃

Application chamber door interlock, gas cabinet interlock, vacuum seal detection compatible with platforms such as Centura and Endura

Features and advantages

High safety design: dual circuit redundant interlocking, shutdown in case of abnormality, to prevent misoperation.

Long lifespan and stability: gold-plated contacts+industrial grade casing, suitable for frequent insertion and removal and harsh environments.

Reliable protection: IP67 dustproof and waterproof, can be used in vacuum and chemical environments.

Signal stability: low contact resistance and high insulation, reducing false alarms.

Easy installation: standard interface, quick replacement, supports on-site customization of circuits.

Key points for installation and maintenance

install

Ensure precise matching between the interlocking actuator and the connector position.

Connect according to the circuit definition, normally closed for safety circuits and normally open for status indication.

Fix firmly to avoid looseness affecting the detection.

debug

Manually open and close the interlocking mechanism, confirm that the contact action is consistent with the main control system signal.

Measure the contact resistance and insulation resistance to ensure they are within the specified range.

maintenance

Regularly clean the contacts and casing to prevent dust, moisture, or chemical corrosion.

Check mechanical wear every 6-12 months and ｒｅｐｌａｃｅ contacts or the entire machine if necessary.

Save calibration and replacement records for easy traceability.
