1.产 品 资 料 介 绍：
- 安装 Festo EMMS-AS-100-S-HS-RRB 需用 100×100mm 法兰支架，固定扭矩 120-150N・cm，避免轴端承受轴向力。
- 接线前确认供电电压与 EMMS-AS-100-S-HS-RRB 额定 565VDC 匹配，防止超压损坏绕组。
- 该型号支持位置 / 速度 / 转矩三模式控制，需搭配 Festo CMMS 系列驱动器配置参数。
- 编码器信号线与动力电缆分开布线，M23 接头需紧固到位，保障 Endat 通信稳定性。
- 定期用干燥抹布清洁 EMMS-AS-100-S-HS-RRB 外壳，IP54 防护需防范灰尘与飞溅液体侵入。
- 运行环境温度控制在 - 40℃至 + 40℃，超温需按 1.5%/℃降容使用。
- 释放抱闸时需先给制动线圈通电，再启动 Festo EMMS-AS-100-S-HS-RRB，避免负载意外移动。
- 电机轴需保持干燥无油污，耦合件安装时禁止敲打轴端，保护 feather key 结构。
- 每 12 个月检测绕组绝缘电阻≥5MΩ，同时校验 PTC 温度监控功能是否正常。
- 闲置超 6 个月重启前，手动转动轴体检查灵活性，空载预热 30 分钟再带载运行。
EMMS-AS-100-S- HS-RRB伺服电机 英文资料：
Installing Festo EMMS-AS-100-S-HS-RRB requires a 100 × 100mm flange bracket with a fixed torque of 120-150N · cm to avoid axial force on the shaft end.
Before wiring, confirm that the power supply voltage matches the rated 565VDC of EMMS-AS-100-S-HS-RRB to prevent overvoltage damage to the winding.
This model supports position/speed/torque three mode control and needs to be matched with Festo CMMS series driver configuration parameters.
The encoder signal line and power cable should be routed separately, and the M23 connector should be securely fastened to ensure Endat communication stability.
Regularly clean the EMMS-AS-100-S-HS-RRB casing with a dry cloth to prevent dust and splashing liquids from entering the IP54 protection.
The operating environment temperature should be controlled between -40 ℃ and+40 ℃. If the temperature exceeds the limit, the capacity should be reduced by 1.5%/℃.
When releasing the brake, first energize the brake coil and then start Festo EMMS-AS-100-S-HS-RRB to avoid accidental load movement.
The motor shaft should be kept dry and free of oil stains. When installing the coupling, it is forbidden to knock the shaft end to protect the feather key structure.
Every 12 months, check the insulation resistance of the winding to be ≥ 5M Ω, and verify whether the PTC temperature monitoring function is normal.
Before restarting after being idle for more than 6 months, manually rotate the shaft to check its flexibility, preheat it for 30 minutes without load, and then run it with load.
Summary: The stable operation core of Festo EMMS-AS-100-S-HS-RRB servo motor lies in standardized installation, communication protection, correct operation of the brake, and environmental adaptation. Relying on the advantages of 1.5kW power, 3.24Nm rated torque, and IP54 protection, combined with compliant maintenance, it can fully exert its precision control performance and ensure reliable operation of the automation system.
EMMS-AS-100-S- HS-RRB伺服电机 产品展示
