1.产 品 资 料 介 绍：
- 安装 DIETZ ELECTRONIC DU-09LB/4P 需选用平整底座，固定扭矩 120-150N・cm，避免运行振动影响精度。
- 接线前确认供电电压与 DU-09LB/4P 额定 230VAC 匹配，防止超压损坏绕组绝缘。
- 该型号支持精密定位控制，需搭配 DIETZ 专用驱动器，确保信号同步与适配性。
- 编码器信号线采用屏蔽线缆单独布线，接头锁紧，减少电磁干扰保障控制精度。
- 定期用干燥抹布清洁 DU-09LB/4P 外壳，表面冷却设计需保持散热面无灰尘遮挡。
- 运行环境温度控制在 - 20℃至 + 70℃，避免剧烈温变，适配工业级工作范围。
- 启动 DIETZ ELECTRONIC DU-09LB/4P 前需检查轴端防腐层是否清理，避免影响耦合安装。
- 耦合件安装使用专用工具牵引，禁止敲打轴端，保护滚动轴承与轴端螺纹结构。
- 每 12 个月检测绕组绝缘电阻≥5MΩ，同时校验电机运行电流不超过额定 3.0A。
- 闲置超 6 个月重启前，手动转动轴体检查灵活性，空载预热 20 分钟再逐步加载。
DU-09LB/4P 伺服电机 英文资料：
The installation of DIETZ ELECTRIC DU-09LB/4P requires a flat base with a fixed torque of 120-150N · cm to avoid the impact of operational vibration on accuracy.
Before wiring, confirm that the power supply voltage matches the rated 230VAC of DU-09LB/4P to prevent overvoltage damage to the winding insulation.
This model supports precise positioning control and requires a DIETZ dedicated driver to ensure signal synchronization and adaptability.
The encoder signal line is separately wired with shielded cables, and the joints are locked to reduce electromagnetic interference and ensure control accuracy.
Regularly clean the DU-09LB/4P casing with a dry cloth, and the surface cooling design should ensure that the heat dissipation surface is free of dust obstruction.
The operating environment temperature is controlled between -20 ℃ and+70 ℃ to avoid severe temperature changes and adapt to industrial grade working range.
Before starting DIETZ ELECTRIC DU-09LB/4P, it is necessary to check whether the anti-corrosion layer on the shaft end is cleaned to avoid affecting the coupling installation.
The installation of coupling components should be carried out using specialized tools for traction. It is prohibited to strike the shaft end to protect the rolling bearings and the threaded structure of the shaft end.
Every 12 months, check the insulation resistance of the winding to be ≥ 5M Ω, and verify that the operating current of the motor does not exceed the rated 3.0A
Before restarting after being idle for more than 6 months, manually rotate the shaft to check its flexibility, preheat for 20 minutes without load, and then gradually load.
Summary: The stable operation core of DIETZ ELECTRIC DU-09LB/4P servo motor lies in voltage matching, standardized installation, heat dissipation guarantee, and regular maintenance. Relying on the stable speed and precise control characteristics of 1470 r/min, it adapts to the precise driving needs of industries such as chemical and pharmaceutical, and with compliant operation, it can fully leverage its industrial grade reliability and adaptability advantages.
DU-09LB/4P 伺服电机 产品展示
