1.产 品 资 料 介 绍：
MDX-03-3A-E113电源控制器相关说明
1. MDX-03-3A-E113为工业级电源控制器，适配电力整流与供电调控场景
2. 平均正向电流300A，可适配大电流工业供电需求
3. 重复峰值反向电压400-2600V可调，适配不同电压等级场景
4. 存储温度范围-40℃至+125℃，环境适应性强
5. 峰值浪涌电流达12.5kA（10ms半正弦波），抗冲击能力优异
6. 具备优异的热稳定性，结壳热阻最大0.130℃/W
7. 支持单相、三相、六相等多种接线模式，适配不同供电系统
8. 隔离电压最小值2500V（50Hz，1分钟），绝缘性能可靠
9. 端子连接扭矩典型值12N·m，安装牢固，接触稳定
10. 适配散热片安装，壳到散热片热阻最大0.04℃/W，散热效率高
11. 板载状态指示灯，实时反馈运行状态与故障信息
12. 安装需专业人员操作，严格遵循扭矩与安装力要求
13. 禁止超压超流使用，使用前需核查电压电流匹配性
14. 接线前必须断开总电源，避免带电操作引发安全事故
15. 出厂经电气性能、热性能等全流程检测，符合工业质量标准
MDX-03-3A-E113电源控制器 英文资料：
MDX-03-3A-E113 power controller related instructions
1. MDX-03-3A-E113 is an industrial grade power controller suitable for power rectification and power supply regulation scenarios
2. Average forward current of 300A, suitable for high current industrial power supply needs
3. The repetitive peak reverse voltage is adjustable from 400-2600V, suitable for different voltage level scenarios
4. The storage temperature range is -40 ℃ to+125 ℃, with strong environmental adaptability
5. The peak surge current reaches 12.5kA (10ms half sine wave), with excellent shock resistance
6. With excellent thermal stability, the maximum thermal resistance of the crust is 0.130 ℃/W
7. Supports multiple wiring modes including single-phase, three-phase, and six phase, adapting to different power supply systems
8. The minimum isolation voltage is 2500V (50Hz, 1 minute), and the insulation performance is reliable
9. The typical torque value for terminal connection is 12N · m, with firm installation and stable contact
10. Suitable for heat sink installation, the maximum thermal resistance from the shell to the heat sink is 0.04 ℃/W, with high heat dissipation efficiency
11. Onboard status indicator light, providing real-time feedback on operating status and fault information
12. Installation requires professional personnel to operate, strictly following torque and installation force requirements
13. Prohibit the use of overpressure and overcurrent. Before use, check the matching of voltage and current
14. Before wiring, the main power supply must be disconnected to avoid safety accidents caused by live operation
15. The factory has undergone full process testing for electrical and thermal performance, and meets industrial quality standards
MDX-03-3A-E113电源控制器 产品展示
