1.产 品 资 料 介 绍：

0190-06279印刷电路板相关说明

1. 0190-06279为工业级印刷电路板（PCB），是电子设备的核心承载与互连部件，适配工业控制、精密仪器等场景

2. 采用FR-4环氧玻璃布基材，具备优异的绝缘性能与机械支撑强度，适配复杂工业环境

3. 铜箔厚度采用标准1oz（35μm），线路传导性能稳定，满足工业设备功率传输需求

4. 采用多层板设计，布线密度高，可实现多组件高效互连，优化信号传输路径

5. 阻焊层采用绿色绝缘油墨，有效防止线路氧化与焊接短路，提升使用可靠性

6. 丝印层标注清晰的元器件位置与参数标识，便于组装、调试及后期维护

7. 最小线宽/间距达4mil（0.1mm），采用精密蚀刻工艺，保障线路连接精度与信号完整性

8. 金属化孔孔径精度±0.075mm，层间连接可靠，降低信号传输损耗

9. 工作温度范围-20℃至60℃，环境适应性强，可稳定运行于常规工业车间与实验室

10. 具备良好的抗电磁干扰能力，线路布局经过优化，减少信号串扰

11. 外形尺寸精度±0.1mm，适配对应设备的安装卡槽，组装兼容性优异

12. 焊接工艺适配常规SMT与THT组装方式，焊盘附着力强，焊接可靠性高

13. 组装前需进行外观检查，确认无线路划伤、焊盘氧化、基材破损等缺陷

14. 存储与运输需防潮、防静电，避免与尖锐物体接触，防止线路损坏

15. 出厂经电气连通性、绝缘电阻等全流程检测，各项指标符合工业PCB质量标准

0190-06279印刷电路板  英文资料：

0190-06279 Instructions for Printed Circuit Boards

0190-06279 is an industrial grade printed circuit board (PCB), which is the core carrier and interconnect component of electronic devices, suitable for industrial control, precision instruments and other scenarios

2. Using FR-4 epoxy glass cloth substrate, it has excellent insulation performance and mechanical support strength, suitable for complex industrial environments

3. The copper foil thickness adopts the standard 1oz (35 μ m), which ensures stable circuit conductivity and meets the power transmission requirements of industrial equipment

4. Adopting a multi-layer board design with high wiring density, it can achieve efficient interconnection of multiple components and optimize signal transmission paths

5. The solder mask layer adopts green insulation ink, effectively preventing circuit oxidation and welding short circuit, and improving the reliability of use

6. Clear labeling of component positions and parameter identification on the silk screen layer facilitates assembly, debugging, and later maintenance

7. The minimum line width/spacing is 4mil (0.1mm), and precision etching technology is used to ensure the accuracy of circuit connection and signal integrity

8. The precision of metalized hole diameter is ± 0.075mm, and the interlayer connection is reliable, reducing signal transmission loss

9. The working temperature range is -20 ℃ to 60 ℃, with strong environmental adaptability, and can operate stably in conventional industrial workshops and laboratories

10. Possess good resistance to electromagnetic interference, optimized circuit layout to reduce signal crosstalk

11. The precision of the external dimensions is ± 0.1mm, which is compatible with the installation slot of the corresponding equipment and has excellent assembly compatibility

12. The welding process is compatible with conventional SMT and THT assembly methods, with strong pad adhesion and high welding reliability

13. Before assembly, a visual inspection is required to confirm defects such as scratches on the wireless path, oxidation of solder pads, and damage to the substrate

14. Storage and transportation should be moisture-proof, anti-static, avoid contact with sharp objects, and prevent damage to the circuit

15. After undergoing full process testing for electrical connectivity, insulation resistance, etc. upon leaving the factory, all indicators meet the industrial PCB quality standards
