1.产 品 资 料 介 绍：

853-088976-004射频匹配盒相关说明

1. 853-088976-004为工业级射频匹配盒，核心功能是实现负载阻抗与射频源的精准匹配，保障射频功率高效传输，适配等离子处理、射频功放等工业射频系统

2. 采用相位-幅值双电容协同调节机制，可动态补偿阻抗偏差，匹配精度高，有效降低反射功率

3. 适配标准50Ω阻抗系统，支持宽频段射频信号匹配，覆盖工业常用射频工作频段

4. 内置高效电感线圈与精密可调电容组件，损耗低，在额定功率范围内匹配效率优异

5. 工作温度范围-10℃至55℃，具备良好的环境适应性，可稳定运行于工业射频设备机房

6. 配备标准SMA射频接口，连接可靠性高，接口特性符合射频信号传输规范，减少信号损耗

7. 支持自动与手动两种匹配模式切换，自动模式可快速响应负载阻抗变化，手动模式适配精准调试需求

8. 内置反射功率监测模块，当反射功率超标时自动触发保护，避免损坏射频源与负载设备

9. 外壳采用金属屏蔽材质，具备优异的抗电磁干扰（EMI）能力，同时防止内部射频信号泄漏

10. 面板配备清晰的状态指示灯与参数显示屏，实时反馈匹配状态、反射功率及工作频段

11. 采用模块化结构设计，安装拆卸便捷，便于后期维护与组件更换

12. 操作前必须确认射频源已关闭，严禁在带电状态下插拔射频接口或打开设备盖板

13. 射频接口连接时需确保对齐到位，拧紧力矩符合规范，避免接触不良导致信号反射或接口损坏

14. 禁止在超过额定功率、额定温度的条件下使用，避免内部组件过热损坏或射频泄漏风险

15. 出厂经阻抗匹配精度、反射功率检测、屏蔽性能测试等全流程验证，符合工业射频设备质量标准

853-088976-004射频匹配盒  英文资料：

853-088976-004 RF matching box related instructions

853-088976-004 is an industrial grade RF matching box, with the core function of achieving precise matching between load impedance and RF source, ensuring efficient transmission of RF power, and adapting to industrial RF systems such as plasma processing and RF power amplifiers

2. Adopting a phase amplitude dual capacitor cooperative adjustment mechanism, it can dynamically compensate for impedance deviation, achieve high matching accuracy, and effectively reduce reflected power

3. Compatible with a standard 50 Ω impedance system, supports wideband RF signal matching, and covers commonly used industrial RF operating frequency bands

4. Built in high-efficiency inductor coils and precision adjustable capacitor components, with low losses and excellent matching efficiency within the rated power range

5. The working temperature range is from -10 ℃ to 55 ℃, with good environmental adaptability, and can operate stably in industrial RF equipment rooms

6. Equipped with standard SMA RF interface, high connection reliability, interface characteristics comply with RF signal transmission specifications, reducing signal loss

7. Supports switching between automatic and manual matching modes. The automatic mode can quickly respond to changes in load impedance, while the manual mode is suitable for precise debugging needs

8. Built in reflection power monitoring module, which automatically triggers protection when the reflection power exceeds the standard, avoiding damage to the RF source and load equipment

9. The shell is made of metal shielding material, which has excellent resistance to electromagnetic interference (EMI) and prevents internal RF signal leakage

10. The panel is equipped with clear status indicator lights and parameter display screens, providing real-time feedback on matching status, reflected power, and operating frequency band

11. Adopting modular structure design, easy installation and disassembly, convenient for later maintenance and component replacement

12. Before operation, it is necessary to confirm that the RF source has been turned off. It is strictly prohibited to plug or unplug the RF interface or open the equipment cover while it is live

13. When connecting the RF interface, ensure that it is aligned properly and the tightening torque meets the specifications to avoid poor contact that may cause signal reflection or interface damage

14. It is prohibited to use it under conditions exceeding the rated power and temperature to avoid the risk of internal component overheating damage or RF leakage

15. The factory has undergone full process verification including impedance matching accuracy, reflected power detection, and shielding performance testing, and meets the quality standards of industrial RF equipment

853-088976-004射频匹配盒 产品展示
