1.产 品 资 料 介 绍：
61234-KEGQ-AWX蝴蝶阀控制系统 产品特点
1. 一体化智能控制设计，集成驱动执行与监测模块，实现蝴蝶阀全流程自动化管控，适配化工、水处理、能源等工业流体系统
2. 采用高精度伺服驱动技术，阀门开度调节精度达±0.5%，分辨率0.1°，可实现流量的精细化管控
3. 响应速度优异，全行程启闭时间≤3秒，紧急切断响应≤0.5秒，适配应急工况快速管控需求
4. 支持PID闭环自动调节，可根据预设流量、压力参数动态修正阀门开度，无需人工干预，保障系统运行稳定性
5. 内置多参数监测模块，实时采集阀门开度、介质流量/压力/温度及电机运行状态，数据采样频率达50Hz
6. 具备故障自诊断功能，可识别阀杆卡涩、密封件磨损、传感器异常等故障，生成故障代码并推送维修建议
7. 支持多模式控制切换，涵盖远程中控、本地手动、定时控制及场景联动，适配不同自动化管理需求
9. 执行机构防护等级达IP67，支持Ex dⅡCT6防爆设计，可在潮湿、多尘、易燃易爆等恶劣工业环境长期稳定运行
10. 配备高清本地显示屏，直观呈现运行参数与状态信息，同时支持历史数据存储与追溯，存储容量≥10万条
11. 具备故障安全模式，气源/电源中断时可自动复位至预设安全位置（全开/全关），降低事故风险
12. 阀体采用多层次密封结构，泄漏等级达ANSI B16.104 Class VI，近乎零泄漏，适配高洁净及高危介质管控场景
13. 模块化结构设计，支持在线更换密封件与执行器，维护便捷，大幅缩短停机维护时间
14. 适配宽工况范围，耐温-40℃至300℃，耐压等级达PN16-PN42，可匹配不同介质与压力等级的管道系统
15. 机械寿命≥10万次循环操作，平均无故障运行时间（MTBF）≥5000小时，运行可靠性高，运维成本低
16. 支持功能模块扩展，可按需添加防爆、流量计量、区块链追溯等模块，适配特殊场景需求
61234-KEGQ-AWX蝴蝶阀控制系统 英文资料：
61234-KEGQ-AWX Butterfly Valve Control System Product Features
1. Integrated intelligent control design, integrated drive execution and monitoring module, realizing full process automation control of butterfly valve, suitable for industrial fluid systems such as chemical, water treatment, energy, etc
2. Adopting high-precision servo drive technology, the valve opening adjustment accuracy reaches ± 0.5%, with a resolution of 0.1 °, which can achieve fine control of flow rate
3. Excellent response speed, with a full travel opening and closing time of ≤ 3 seconds and an emergency cut-off response time of ≤ 0.5 seconds, suitable for rapid control needs in emergency working conditions
4. Support PID closed-loop automatic adjustment, which can dynamically adjust valve opening according to preset flow and pressure parameters without manual intervention, ensuring system operation stability
5. Built in multi parameter monitoring module, real-time collection of valve opening, medium flow/pressure/temperature, and motor operation status, with a data sampling frequency of 50Hz
6. Equipped with fault self diagnosis function, it can identify faults such as valve stem jamming, seal wear, sensor abnormalities, etc., generate fault codes, and push repair suggestions
7. Support multi-mode control switching, covering remote central control, local manual control, timed control, and scene linkage, adapting to different automation management needs
9. The protection level of the actuator reaches IP67, supporting Ex d Ⅱ CT6 explosion-proof design, and can operate stably for a long time in harsh industrial environments such as humidity, dust, flammability, and explosiveness
10. Equipped with high-definition local display screen, visually presenting operating parameters and status information, while supporting historical data storage and traceability, with a storage capacity of ≥ 100000 records
11. Equipped with a fail safe mode, it can automatically reset to the preset safe position (fully open/fully closed) when the gas/power supply is interrupted, reducing the risk of accidents
12. The valve body adopts a multi-level sealing structure, with a leakage level of ANSI B16.104 Class VI, almost zero leakage, suitable for high cleanliness and high-risk medium control scenarios
13. Modular structure design, supporting online replacement of seals and actuators, easy maintenance, significantly reducing downtime for maintenance
14. Suitable for a wide range of working conditions, with a temperature resistance of -40 ℃ to 300 ℃ and a pressure resistance level of PN16-PN42, it can be matched with pipeline systems of different media and pressure levels
15. Mechanical lifespan ≥ 100000 cycles of operation, mean time between failures (MTBF) ≥ 5000 hours, high operational reliability, and low maintenance costs
16. Support functional module expansion, which can add explosion-proof, traffic measurement, blockchain traceability and other modules as needed to adapt to special scenario requirements
