1.产 品 资 料 介 绍：
660-285651-004射频匹配模块 英文资料：
1. Module handling and installation should be handled with care to avoid severe vibration that may damage internal components
2. Before starting the homework, it is necessary to check whether the power supply voltage meets the rated requirements of the module to prevent overvoltage and burnout
Before connecting coaxial cables, it is necessary to clean the interface debris to ensure good contact between the metal contacts
4. The cable connection must be firm, and it is strictly prohibited to turn on the RF power before it is properly connected
5. The first debugging requires adjusting the power to the lowest level, gradually increasing and synchronously adjusting the matching knob
6. Matching debugging aims to minimize the reflected power, and it is recommended to have a forward to reverse power ratio of ≥ 10:1
After replacing the load terminal, it is necessary to re execute the matching debugging process for low-power startup
8. The module casing must be reliably grounded, and the cross-sectional area of the grounding conductor must not be less than 2.5mm ²
9. RF wiring must strictly follow the 50 ohm impedance requirement to avoid excessive detours
10. The matching circuit area should be kept clear and other components or debris should not be stacked
11. The power cord and RF cable should be wired separately and should not be crossed or bundled together
When the device is idle, the power should be disconnected to avoid prolonged standby and accelerated component aging
13. After debugging is completed, record the position of the knob for quick recovery of matching status in the future
14. Regularly inspect cable joints for erosion and oxidation, and promptly clean or ｒｅｐｌａｃｅ them
15. Before opening the cover for maintenance, the power must be turned off and wait for at least 5 minutes to confirm that there is no residual high voltage
660-285651-004射频匹配模块 产品展示
