1.产 品 资 料 介 绍：

HGD-3000氢烟温多参数探测器产品说明

注：HGD-3000并非单纯的温度探测器，而是一款集成氢气检测、烟雾检测、温度监测及可选入侵报警功能的多参数安全监测设备（主流型号为Eagle Eye Power Solutions旗下产品），核心定位为无人值守电池房、远程机房等场景的安全防护，可实现24小时连续监测与自动应急响应。以下为其核心信息梳理：

一、核心技术特性

- 多参数集成监测：搭载高灵敏度固态氢传感器、光电烟雾传感器及内置恒温器，可同时监测氢气浓度、烟雾、环境温度三大核心安全参数，还支持可选红外入侵监测功能；

- 精准响应与分级联动：氢气浓度达1%时自动启动排风风扇，达2%（低于氢气4.1%爆炸下限）时触发报警；温度超预设阈值（默认40℃，可调范围±5℃）自动启动排风降温，烟雾检测到燃烧产物时立即触发独立报警并禁止排风（防止供氧助燃）；

- 多维报警机制：配备80dB本地蜂鸣器、红色闪烁LED指示灯，同时具备干触点开关，可实现远程报警联动，掉电状态也能触发干触点报警；

- 工业级适配性：工作温度范围-10～40℃（14～104°F），符合NFPA 2、IEEE 450等多项行业标准，适用于1区2组B类危险环境；支持85～265VAC（50/60Hz）或17～60VDC宽电压供电，尺寸小巧（178×120×55mm），可壁装、吊顶安装或通过接线盒安装。

二、核心应用领域

- 电力能源场景：适用于UPS电源系统机房、铅酸蓄电池充电房、燃料电池测试站、水电站/火电站辅助机房，防范电池充电产生氢气积聚及电气火灾风险；

- 通信与公用事业：适配电信基站远程机房、公用事业远端庇护所，保障无人值守场景下的设备安全与环境稳定；

- 特种能源场景：可用于氢燃料加注站、核废料重整设施等含氢环境，实现氢气泄漏与火灾隐患的早期预警；

- 其他工业场景：适用于高尔夫球车等动力电池存放区、工业储能电池舱等，提供全方位安全监测防护。

HGD-3000温度探测器  英文资料：

HGD-3000 Hydrogen Smoke Temperature Multi Parameter Detector Product Description

Note: The HGD-3000 is not simply a temperature detector, but a multi parameter safety monitoring device that integrates hydrogen detection, smoke detection, temperature monitoring, and optional intrusion alarm functions (mainstream models are products under Eagle Eye Power Solutions). Its core positioning is security protection for unmanned battery rooms, remote computer rooms, and other scenarios, and it can achieve 24-hour continuous monitoring and automatic emergency response. The following is a summary of its core information:

1、 Core technical characteristics

-Multi parameter integrated monitoring: equipped with high-sensitivity solid-state hydrogen sensors, photoelectric smoke sensors, and built-in thermostats, it can simultaneously monitor the three core safety parameters of hydrogen concentration, smoke, and ambient temperature. It also supports optional infrared intrusion monitoring function;

-Accurate response and graded linkage: When the hydrogen concentration reaches 1%, the exhaust fan will automatically start, and when it reaches 2% (below the lower explosive limit of 4.1% hydrogen), an alarm will be triggered; When the temperature exceeds the preset threshold (default 40 ℃, adjustable range ± 5 ℃), automatic exhaust cooling will be activated. When smoke detects combustion products, an independent alarm will be triggered immediately and exhaust will be prohibited (to prevent oxygen supply and combustion assistance);

-Multi dimensional alarm mechanism: equipped with an 80dB local buzzer, red flashing LED indicator light, and a dry contact switch, which can achieve remote alarm linkage and trigger dry contact alarm even in power failure state;

-Industrial grade adaptability: Operating temperature range of -10~40 ℃ (14~104 ° F), in compliance with multiple industry standards such as NFPA 2 and IEEE 450, suitable for Class B hazardous environments in Zone 1 and Group 2; Supports 85-265VAC (50/60Hz) or 17-60VDC wide voltage power supply, with a small size (178 × 120 × 55mm), and can be wall mounted, ceiling mounted, or installed through junction boxes.

2、 Core application areas

-Power energy scenario: suitable for UPS power system rooms, lead-acid battery charging rooms, fuel cell testing stations, auxiliary rooms of hydropower/thermal power stations, to prevent hydrogen accumulation and electrical fire risks caused by battery charging;

-Communication and Public Utilities: Adapt to remote data centers for telecommunications base stations and remote shelters for public utilities, ensuring equipment safety and environmental stability in unmanned scenarios;

-Special energy scenarios: can be used in hydrogen containing environments such as hydrogen fuel injection stations and nuclear waste reforming facilities to achieve early warning of hydrogen leakage and fire hazards;

-Other industrial scenarios: Suitable for power battery storage areas such as golf carts, industrial energy storage battery compartments, etc., providing comprehensive safety monitoring and protection.

HGD-3000温度探测器  产品展示
