1.产 品 资 料 介 绍：

E3174-T0001矢量控制器产品说明

注：结合行业产品命名规律及公开技术资料推测，E3174-T0001矢量控制器大概率与倍福（Beckhoff）EL3174系列产品存在技术关联，其核心定位为工业自动化领域的高精度矢量控制专用器件，主要用于交流电机的矢量驱动控制，凭借精准的磁场定向控制能力，实现电机转速、转矩的高精度调节。以下为其核心信息梳理：

一、核心技术特性

- 矢量控制核心：采用磁场定向控制（FOC）算法，可实现交流异步电机、永磁同步电机的高精度转矩/转速闭环控制，动态响应速度快，稳态控制精度高；

- 信号适配能力：兼容多类型反馈信号（如编码器、霍尔传感器信号），支持与高精度模拟量输入模块协同工作，可精准采集电机运行参数（电流、电压、转速等）；

- 工业级可靠性：具备优异的抗电磁干扰能力，符合EN 61000-6-2/EN 61000-6-4工业电磁兼容标准，工作温度范围适配工业场景（-25…+60℃），防护等级达IP20；

- 总线通信支持：大概率兼容EtherCAT工业实时总线，可实现与上位控制器（如TwinCAT系统）的高速数据交互，分布式时钟精度优于1μs，保障多设备协同控制的同步性。

二、核心应用领域

- 工业机器人：用于机器人关节电机的驱动控制，实现关节的高精度定位与平稳运动，保障机器人作业精度；

- 数控机床：适配机床主轴、进给轴电机控制，通过精准的转速与转矩调节，提升机床加工精度与表面质量；

- 自动化生产线：用于输送线、分拣设备等传动机构的电机控制，实现调速与定位的精准协同，提升生产线运行效率；

- 新能源装备：可用于光伏、风电等新能源设备的传动系统控制，适配极端工况下的稳定运行需求。

E3174-T0001矢量控制器  英文资料：

E3174-T0001 Vector Controller Product Description

Note: Based on the naming conventions of industry products and publicly available technical information, it is highly likely that the E3174-T0001 vector controller is technically related to the Beckhoff EL3174 series products. Its core positioning is as a high-precision vector control specialized device in the field of industrial automation, mainly used for vector drive control of AC motors. With precise magnetic field orientation control capabilities, it achieves high-precision adjustment of motor speed and torque. The following is a summary of its core information:

1、 Core technical characteristics

-Vector Control Core: Using Field Oriented Control (FOC) algorithm, high-precision torque/speed closed-loop control of AC asynchronous motors and permanent magnet synchronous motors can be achieved, with fast dynamic response speed and high steady-state control accuracy;

-Signal adaptation capability: Compatible with multiple types of feedback signals (such as encoder and Hall sensor signals), supports collaborative work with high-precision analog input modules, and can accurately collect motor operating parameters (current, voltage, speed, etc.);

-Industrial grade reliability: It has excellent anti electromagnetic interference capability, complies with EN 61000-6-2/EN 61000-6-4 industrial electromagnetic compatibility standards, and is suitable for industrial scenarios (-25...+60 ℃) with a protection level of IP20;

-Bus communication support: It is highly compatible with EtherCAT industrial real-time bus and can achieve high-speed data exchange with upper level controllers (such as TwinCAT system). The distributed clock accuracy is better than 1 μ s, ensuring the synchronization of multi device collaborative control.

2、 Core application areas

-Industrial robots: used for driving and controlling the joint motors of robots, achieving high-precision positioning and smooth motion of joints, ensuring the accuracy of robot operations;

-CNC machine tools: adapted to control the spindle and feed axis motors of machine tools, improving machining accuracy and surface quality through precise speed and torque adjustment;

-Automated production line: used for motor control of transmission mechanisms such as conveyor lines and sorting equipment, achieving precise coordination of speed regulation and positioning, and improving the operational efficiency of the production line;

-New energy equipment: It can be used for controlling the transmission system of new energy equipment such as photovoltaics and wind power, and is suitable for stable operation under extreme working conditions.

E3174-T0001矢量控制器  产品展示

产品视频
