670EC-24CQ-AIJ外置控制器模块

670EC-24CQ-AIJ外置控制器模块

1.产 品 资 料 介 绍：

670EC-24CQ-AIJ外置控制器模块 产品特点

1. 工业级外置扩展控制器模块，专为自动化系统I/O扩展与分布式控制场景设计，可无缝对接主流PLC与工控主机，提升系统控制灵活性

2. 配备24路多功能I/O通道，支持数字量输入/输出、模拟量采集自由配置，模拟量输入分辨率达16位，保障数据采集精准度

3. 兼容Modbus-RTU/TCP主流工业通讯协议，配备RS-485与以太网双通讯接口，实现与上位系统的高速数据交互

4. 支持即插即用扩展，无需复杂配置即可完成与主机系统的联动，大幅降低系统扩容与调试成本

5. 搭载工业级高稳定核心芯片，平均无故障运行时间（MTBF）≥150,000小时，适配7×24小时连续工业运行需求

6. 工作电压适配DC 24V±10%宽范围供电，具备过压、过流及反接保护功能，保障供电系统安全稳定

7. 采用全封闭铸铝外壳设计，防护等级达IP67，可有效抵御粉尘、湿气侵入，适配恶劣工业现场环境

8. 工作温度范围-40℃至70℃，存储温度-50℃至85℃，具备优异的高低温适应性，可稳定运行于严寒、高温等极端环境

9. 配备三色LED状态指示灯，精准呈现电源、通讯、通道工作及故障状态，故障定位直观高效

10. 采用标准化DIN导轨安装设计，尺寸紧凑适配狭小安装空间，安装拆卸便捷，便于系统布局与后期维护

11. 支持通道级故障自诊断功能，可实时监测I/O通道异常并上报故障信息，保障系统运行可靠性

12. 采用镀金密封接插件，具备防误插与自锁功能，连接可靠性高，适配工业现场频繁振动环境

13. 支持软件配置安全冗余机制，通讯中断时可自动将输出通道切换至预设安全状态，降低系统风险

14. 符合EN 61000系列工业电磁兼容标准，抗电磁干扰能力优异，可与变频器、电机等强干扰设备协同稳定运行

15. 支持多模块级联扩展，可根据系统需求灵活增减模块数量，轻松实现大规模分布式控制网络构建

670EC-24CQ-AIJ外置控制器模块  英文资料：

670EC-24CQ-AIJ External Controller Module Product Features

1. Industrial grade external expansion controller module, designed specifically for I/O expansion and distributed control scenarios in automation systems, can seamlessly integrate with mainstream PLCs and industrial control hosts, enhancing system control flexibility

2. Equipped with 24 multifunctional I/O channels, supporting free configuration of digital input/output and analog acquisition, with an analog input resolution of 16 bits to ensure data acquisition accuracy

3. Compatible with mainstream industrial communication protocols such as Modbus RTU/TCP, equipped with dual communication interfaces of RS-485 and Ethernet, to achieve high-speed data exchange with the upper system

4. Support plug and play expansion, complete linkage with the host system without complex configuration, significantly reducing system expansion and debugging costs

5. Equipped with industrial grade high stability core chips, with an average time between failures (MTBF) of ≥ 150000 hours, suitable for 7 × 24-hour continuous industrial operation requirements

6. The working voltage is suitable for a wide range of DC 24V ± 10% power supply, with overvoltage, overcurrent, and reverse connection protection functions to ensure the safety and stability of the power supply system

7. Adopting a fully enclosed cast aluminum shell design with a protection level of IP67, it can effectively resist the invasion of dust and moisture, and is suitable for harsh industrial site environments

8. The working temperature range is -40 ℃ to 70 ℃, and the storage temperature is -50 ℃ to 85 ℃. It has excellent high and low temperature adaptability and can operate stably in extreme environments such as severe cold and high temperature

9. Equipped with three color LED status indicator lights, it accurately presents the power, communication, channel operation and fault status, and fault location is intuitive and efficient

10. Adopting standardized DIN rail installation design, compact size suitable for narrow installation space, easy installation and disassembly, convenient system layout and later maintenance

11. Support channel level fault self diagnosis function, which can monitor I/O channel abnormalities in real time and report fault information, ensuring the reliability of system operation

12. Adopting gold-plated sealed connectors with anti misoperation and self-locking functions, the connection reliability is high, and it is suitable for frequent vibration environments in industrial sites

13. Support software configuration security redundancy mechanism, which can automatically switch the output channel to the preset security state when communication is interrupted, reducing system risks

14. Compliant with the EN 61000 series industrial electromagnetic compatibility standards, with excellent resistance to electromagnetic interference, and can operate stably in coordination with strong interference equipment such as frequency converters and motors

15. Support cascading expansion of multiple modules, flexible increase or decrease in module quantity according to system requirements, and easy implementation of large-scale distributed control network construction

670EC-24CQ-AIJ外置控制器模块  产品展示
