1.产 品 资 料 介 绍：
PXIe-1435是美国国家仪器（NI）推出的PXI Express（PXIe）总线图像采集设备，核心定位为机器视觉与自动化测试领域的高速图像采集核心组件，可适配多种配置的Camera Link相机，具备Camera Link供电（PoCL）功能，能实现高质量图像数据的快速采集与传输，广泛适配各类高精度视觉检测与图像分析场景。核心信息如下：
一、核心技术特性
- 多规格相机适配：全面支持Base、Medium、Full及Extended Full配置的Camera Link相机，兼容不同分辨率与帧率需求的视觉采集设备，适配性广泛；
- 集成供电功能：支持Power over Camera Link（PoCL）技术，可通过Camera Link线缆为相机直接供电，无需额外电源模块，简化系统布线与集成复杂度；
- 高速总线传输：依托PXIe总线架构，实现图像数据的高速、低延迟传输，保障海量图像数据从采集到存储/处理的高效流转，适配实时视觉分析需求；
- 高可靠性设计：符合工业级安全规范，具备良好的电磁兼容性与环境适应性，设备损坏时需由专业人员检修，避免非授权改装，保障长期稳定运行；
- 便捷系统集成：需配合Camera Link相机、专用线缆等组件使用，支持与NI相关硬件及软件平台无缝集成，简化视觉检测系统的搭建与调试流程。
二、核心应用领域
- 工业视觉检测：适用于自动化生产线的产品缺陷检测、尺寸测量、外观识别等场景，如电子元件引脚检测、汽车零部件装配校验，保障产品质量；
- 精密制造与计量：适配精密加工设备的视觉定位与尺寸校准，如半导体芯片封装检测、3C产品精密组件装配引导，提升制造精度与自动化水平；
- 科研与实验室场景：用于机器视觉算法研发、图像采集与分析相关实验，为视觉技术研究提供稳定的图像数据采集支撑；
- 自动化测试系统：集成于各类产品的自动化测试平台，通过图像采集与分析实现对被测对象的可视化检测，提升测试效率与准确性。
PXIe-1435图像采集设备 英文资料：
PXIe-1435 is a PXI Express (PXIe) bus image acquisition device launched by National Instruments (NI) in the United States. It is positioned as a high-speed image acquisition core component in the field of machine vision and automation testing, and can adapt to various configurations of Camera Link cameras. It has Camera Link Power Supply (PoCL) function, which can achieve fast acquisition and transmission of high-quality image data and is widely applicable to various high-precision visual inspection and image analysis scenarios. The core information is as follows:
1、 Core technical characteristics
-Multi specification camera adaptation: Camera Link cameras that fully support Base, Medium, Full, and Extended Full configurations are compatible with visual capture devices with different resolution and frame rate requirements, and have a wide range of adaptability;
-Integrated power supply function: Supports Power over Camera Link (PoCL) technology, which can directly power the camera through the Camera Link cable without the need for additional power modules, simplifying system wiring and integration complexity;
-High speed bus transmission: relying on the PXIe bus architecture, high-speed and low latency transmission of image data is achieved, ensuring efficient flow of massive image data from acquisition to storage/processing, and adapting to real-time visual analysis requirements;
-High reliability design: compliant with industrial safety standards, with good electromagnetic compatibility and environmental adaptability. In case of equipment damage, it needs to be repaired by professional personnel to avoid unauthorized modifications and ensure long-term stable operation;
-Convenient system integration: It needs to be used in conjunction with Camera Link cameras, dedicated cables, and other components to support seamless integration with NI related hardware and software platforms, simplifying the process of building and debugging visual inspection systems.
2、 Core application areas
-Industrial visual inspection: suitable for product defect detection, size measurement, appearance recognition and other scenarios in automated production lines, such as electronic component pin detection, automotive component assembly verification, to ensure product quality;
-Precision Manufacturing and Metrology: Adapt to the visual positioning and dimensional calibration of precision machining equipment, such as semiconductor chip packaging inspection, 3C product precision component assembly guidance, to improve manufacturing accuracy and automation level;
-Research and laboratory scenarios: used for machine vision algorithm development, image acquisition and analysis related experiments, providing stable image data acquisition support for visual technology research;
-Automated testing system: an automated testing platform integrated into various products, which achieves visual detection of the tested object through image acquisition and analysis, improving testing efficiency and accuracy.
