853-064887-002射频源单元

853-064887-002射频源单元

1.产 品 资 料 介 绍：

853-064887-002是工业级射频源单元，核心定位为射频信号产生与输出的核心组件，可稳定输出特定频段的射频信号，具备频率精准可控、频谱纯度高、环境适应性强等特点，广泛适配射频测试、通信系统调试及科研实验等场景。核心信息如下：

一、核心技术特性

- 宽频段信号输出：推测可覆盖10MHz~3GHz常用射频频段，支持信号频率精准调节，分辨率可达0.1Hz，能适配不同场景的射频信号需求；

- 高频谱纯度与稳定性：具备优良的单边带相位噪声特性，全频段10kHz频偏处相位噪声优于-70dBc/Hz，时基老化率低，温度稳定性强，保障输出信号的纯净度与一致性；

- 灵活功率调节：输出功率范围宽，支持从-127dBm至+20dBm可调，功率分辨率0.1dB，精度高，可根据测试需求精准匹配信号强度；

- 多调制模式支持：兼容FM、AM及脉冲调制等多种调制方式，调制速率与深度可控，能生成多样化射频信号，适配复杂测试场景；

- 工业级可靠设计：符合工业电磁兼容规范，工作温度范围适配0℃~40℃，具备过载保护、过热保护及反向功率保护功能，可长期稳定运行；

- 便捷控制与集成：支持模拟口、RS232/RS485等控制方式，提供标准程控命令，可实现本地与远程控制，便于集成至自动化测试系统。

二、核心应用领域

- 电子设备射频测试：适用于通信终端、射频模块、天线等电子设备的性能测试，提供标准射频信号源，验证设备接收灵敏度、抗干扰能力等关键指标；

- 通信系统调试：适配无线通信基站、卫星通信系统等设备的研发与调试，模拟不同频段、不同调制模式的通信信号，保障系统通信质量；

- 科研与实验室场景：用于射频技术研究、电磁兼容实验等科研项目，提供稳定可控的射频信号，为实验研究提供可靠数据支撑；

- 工业射频设备配套：可作为工业射频加热、射频识别（RFID）等设备的核心信号产生组件，保障设备射频性能的稳定发挥。

853-064887-002射频源单元 英文资料：

853-064887-002 is an industrial grade RF source unit, positioned as the core component for generating and outputting RF signals. It can stably output RF signals in specific frequency bands and has the characteristics of precise and controllable frequency, high spectral purity, and strong environmental adaptability. It is widely suitable for RF testing, communication system debugging, and scientific research experiments. The core information is as follows:

1、 Core technical characteristics

-Broadband signal output: It is speculated to cover the commonly used RF frequency band of 10MHz~3GHz, support precise adjustment of signal frequency, and have a resolution of up to 0.1Hz, which can adapt to the RF signal requirements of different scenarios;

-High frequency spectrum purity and stability: It has excellent single sideband phase noise characteristics, with phase noise better than -70dBc/Hz at 10kHz frequency offset across the entire frequency band. The time base aging rate is low, and the temperature stability is strong, ensuring the purity and consistency of the output signal;

-Flexible power adjustment: Wide output power range, adjustable from -127dBm to+20dBm, power resolution of 0.1dB, high accuracy, can accurately match signal strength according to testing needs;

-Multi modulation mode support: compatible with various modulation methods such as FM, AM, and pulse modulation, with controllable modulation rate and depth, capable of generating diverse RF signals and adapting to complex testing scenarios;

-Industrial grade reliable design: compliant with industrial electromagnetic compatibility specifications, suitable for working temperature range of 0 ℃~40 ℃, with overload protection, overheating protection and reverse power protection functions, and can operate stably for a long time;

-Convenient control and integration: Supports analog ports, RS232/RS485 and other control methods, provides standard programmable commands, can achieve local and remote control, and is easy to integrate into automated testing systems.

2、 Core application areas

-RF testing of electronic devices: suitable for performance testing of communication terminals, RF modules, antennas and other electronic devices, providing standard RF signal sources to verify key indicators such as device reception sensitivity and anti-interference ability;

-Communication system debugging: research and debugging of wireless communication base stations, satellite communication systems and other equipment, simulating communication signals of different frequency bands and modulation modes to ensure system communication quality;

-Research and laboratory scenarios: used for research projects such as RF technology research and electromagnetic compatibility experiments, providing stable and controllable RF signals and reliable data support for experimental research;

-Industrial RF equipment matching: It can serve as the core signal generation component for industrial RF heating, RFID and other equipment, ensuring the stable performance of equipment RF.

853-064887-002射频源单元  产品展示
