1.产 品 资 料 介 绍：

TDS744A是泰克（Tektronix）推出的四通道数字化示波器，隶属于700A系列，核心定位为先进数字与模拟设计的测试测量工具，具备高带宽、高采样率及多模式采集能力，可精准捕捉和分析高速电信号，广泛适配研发、调试等各类测试测量场景。核心信息如下：

一、核心技术特性

- 高规格信号采集：模拟带宽达500MHz，最大采样率2GS/s（四通道同时工作），单通道最大记录长度50,000点（可选配扩展至500,000点），可精准捕捉高速信号与细微波形变化；

- 多模式采集与触发：支持采样、包络、平均、高分辨率及峰值检测等多种采集模式；触发功能丰富，涵盖边缘、逻辑、脉冲触发，可选配视频触发（支持NTSC、SECAM、PAL、HDTV等格式），可精准捕获目标信号；

- 精准信号分析：垂直分辨率8位，高分辨率模式下可达13位以上，直流增益精度±1.0%；内置25种自动测量功能，支持FFT、积分、微分等运算，助力快速完成信号分析；

- 便捷显示与存储：配备7英寸彩色液晶显示屏，可清晰区分多通道波形与测量数据；支持3.5英寸DOS格式软盘存储，具备GPIB、RS-232、Centronics等接口，可实现远程控制与硬拷贝输出；

- 灵活便携设计：机身便携，操作界面友好，通过前面板按钮、旋钮与屏幕菜单组合控制，常用参数可直接调节，适配实验室与现场测试等多种场景。

二、核心应用领域

- 电子研发与调试：适用于数字电路、模拟电路研发及故障排查，可精准捕捉芯片、电路板的高速电信号，分析信号失真、时序偏差等问题，为设计优化提供数据支持；

- 通讯设备测试：用于通讯模块、传输链路的信号测试，监测信号传输稳定性与抗干扰能力，保障通讯设备性能达标；

- 工业电子检测：适配工业控制模块、传感器等设备的电气性能测试，验证信号输出精度与稳定性，助力工业设备质量把控；

- 科研与教育：可作为高校电子工程专业教学实验设备，及科研机构高速信号相关研究的测试工具，直观呈现信号特性。

TDS744A示波器 英文资料：

TDS744A is a four channel digital oscilloscope launched by Tektronix, belonging to the 700A series. Its core positioning is as an advanced digital and analog design testing and measurement tool, with high bandwidth, high sampling rate, and multi-mode acquisition capabilities. It can accurately capture and analyze high-speed electrical signals and is widely applicable to various testing and measurement scenarios such as research and development, debugging, etc. The core information is as follows:

1、 Core technical characteristics

-High specification signal acquisition: analog bandwidth up to 500MHz, maximum sampling rate of 2GS/s (four channels working simultaneously), maximum recording length of 50000 points per channel (optional extension to 500000 points), can accurately capture high-speed signals and subtle waveform changes;

-Multi mode acquisition and triggering: supports multiple acquisition modes such as sampling, envelope, averaging, high-resolution, and peak detection; Rich triggering functions, covering edge, logic, pulse triggering, and optional video triggering (supporting NTSC, SECAM, PAL, HDTV formats, etc.), can accurately capture target signals;

-Accurate signal analysis: vertical resolution of 8 bits, up to 13 bits or more in high-resolution mode, DC gain accuracy of ± 1.0%; Built in 25 automatic measurement functions, supporting FFT, integration, differentiation and other operations, helping to quickly complete signal analysis;

-Convenient display and storage: Equipped with a 7-inch color LCD display screen, it can clearly distinguish multi-channel waveforms and measurement data; Supports 3.5-inch DOS format floppy disk storage, with interfaces such as GPIB, RS-232, Centronics, etc., enabling remote control and hard copy output;

-Flexible and portable design: The body is portable, with a user-friendly interface. It can be controlled through a combination of front panel buttons, knobs, and screen menus. Common parameters can be directly adjusted, making it suitable for various scenarios such as laboratory and on-site testing.

2、 Core application areas

-Electronic R&D and Debugging: Suitable for the R&D and troubleshooting of digital and analog circuits, it can accurately capture high-speed electrical signals of chips and circuit boards, analyze signal distortion, timing deviation and other issues, and provide data support for design optimization;

-Communication equipment testing: used for signal testing of communication modules and transmission links, monitoring signal transmission stability and anti-interference ability, and ensuring that communication equipment performance meets standards;

-Industrial electronic testing: Suitable for electrical performance testing of industrial control modules, sensors, and other equipment, verifying signal output accuracy and stability, and assisting in quality control of industrial equipment;

-Research and Education: It can be used as teaching and experimental equipment for electronic engineering majors in universities, as well as testing tools for high-speed signal related research in research institutions, to visually present signal characteristics.

TDS744A示波器  产品展示

产品视频
