1.产 品 资 料 介 绍：

X7-3P3P1L1L-12电源供应模块 产品概述及应用领域

X7-3P3P1L1L-12电源供应模块是一款具备高可靠性与灵活扩展性的工业级模块化供电单元，采用宽范围AC输入设计与主动式功率因数校正（PFC）技术，转换效率高且纹波噪声低。其支持输出电压精准调节与远程控制，集成过压、过载、短路、过热等多重保护机制，具备优异的抗冲击与抗电磁干扰能力，可适配-20~+70℃宽温工业环境。该模块支持并联/串联配置扩展功率，配备AC OK、DC OK等状态信号，能为各类工业电子设备提供持续稳定的供电支持，核心应用如下：

一、工业自动化与智能制造领域

核心场景：为PLC控制器、伺服驱动器、分布式I/O模块及工业传感器网络提供稳定直流供电，凭借低纹波特性保障控制信号精准传输；适配自动化生产线的控制柜系统，宽电压输入特性可应对电网波动，支持150%额定电流短时过载以适应电机、电磁阀启动冲击；通过远程开/关与状态监测功能，实现电源运行状态实时管控，便于生产线运维与故障诊断，适配汽车制造、电子加工等高端制造场景。

二、通信与网络基础设施领域

核心场景：作为通信基站、数据中心的辅助供电单元，为路由器、交换机及网络监测设备提供稳定供电，低空载功耗特性降低能源损耗；适配无人值守通信站点，凭借宽温工作与高可靠性设计，在户外恶劣环境下保障通信设备7×24小时连续运行；支持与UPS系统联动，在电网中断时实现无缝供电切换，保障网络数据传输连续性。

三、新能源与电力电子领域

核心场景：应用于光伏逆变器、储能系统的控制单元，为电池管理系统（BMS）与监测模块提供可靠电源，适应户外高低温环境波动；适配风电控制系统的通信与传感器供电，具备强抗电磁干扰能力保障数据传输稳定；用于智能变电站的继电保护装置与远程终端（RTU）供电，高电压稳定精度确保电力调度指令准确执行。

四、特种仪器与轨道交通领域

核心场景：为工业检测仪器、精密分析设备提供高精度供电，低纹波噪声保障检测数据精准性；适配轨道交通车载电子设备，耐受强振动与高低温循环，为车载通信、定位与安全监测系统稳定供电；用于医疗诊断设备（如监护仪、分析仪）的辅助供电，符合工业安全认证标准，具备安全隔离特性，保障设备运行安全与患者安全。

X7-3P3P1L1L-12电源供应模块 英文资料：

X7-3P3P1L1L12 Power Supply Module Product Overview and Application Fields

The X7-3P3P1L1L-12 power supply module is an industrial modular power supply unit with high reliability and flexible scalability. It adopts a wide range AC input design and active power factor correction (PFC) technology, with high conversion efficiency and low ripple noise. It supports precise adjustment and remote control of output voltage, integrates multiple protection mechanisms such as overvoltage, overload, short circuit, and overheating, and has excellent resistance to impact and electromagnetic interference. It can adapt to industrial environments with a wide temperature range of -20~+70 ℃. This module supports parallel/series configuration to expand power, equipped with AC OK, DC OK and other status signals, and can provide continuous and stable power supply support for various industrial electronic devices. The core applications are as follows:

1、 In the field of industrial automation and intelligent manufacturing

Core scenario: Provide stable DC power supply for PLC controllers, servo drives, distributed I/O modules, and industrial sensor networks, ensuring precise transmission of control signals with low ripple characteristics; The control cabinet system adapted for automated production lines has a wide voltage input characteristic that can cope with power grid fluctuations, and supports 150% rated current short-term overload to adapt to motor and solenoid valve start-up shocks; Through remote on/off and status monitoring functions, real-time control of power operation status is achieved, facilitating production line operation and fault diagnosis, and adapting to high-end manufacturing scenarios such as automotive manufacturing and electronic processing.

2、 In the field of communication and network infrastructure

Core scenario: As an auxiliary power supply unit for communication base stations and data centers, it provides stable power supply for routers, switches, and network monitoring equipment, with low no-load power consumption characteristics to reduce energy loss; Adapting to unmanned communication stations, with wide temperature operation and high reliability design, ensuring continuous operation of communication equipment 7 × 24 hours in harsh outdoor environments; Support linkage with UPS system to achieve seamless power switching in case of grid interruption, ensuring the continuity of network data transmission.

3、 In the field of new energy and power electronics

Core scenario: Applied to control units of photovoltaic inverters and energy storage systems, providing reliable power for battery management systems (BMS) and monitoring modules, adapting to outdoor high and low temperature environmental fluctuations; Adapt to the communication and sensor power supply of wind power control system, with strong anti electromagnetic interference capability to ensure stable data transmission; The relay protection device and remote terminal unit (RTU) used for intelligent substations are powered by high voltage stability accuracy to ensure accurate execution of power dispatch instructions.

4、 Special instruments and rail transit field

Core scenario: Provide high-precision power supply for industrial testing instruments and precision analysis equipment, with low ripple noise to ensure the accuracy of testing data; Adapt to on-board electronic equipment of rail transit, withstand strong vibrations and high and low temperature cycles, and provide stable power supply for on-board communication, positioning, and safety monitoring systems; Used as an auxiliary power supply for medical diagnostic equipment (such as monitors and analyzers), it meets industrial safety certification standards, has safety isolation characteristics, and ensures the safe operation of equipment and patient safety.

X7-3P3P1L1L-12电源供应模块 产品展示

产品视频
