1.产 品 资 料 介 绍：
810-801237-500步进驱动器模块产品特点
- 采用32位DSP核心控制技术，驱动性能稳定，适配高精度运动控制场景
- 支持DC20-35V宽电压输入，适配多种工业电源供给，通用性强
- 具备16档细分可调功能，最高细分达60000步/转，定位精度优异
- 集成增强式细分技术，可自动平滑运动轨迹，解决低细分低速抖动问题
- 支持4档驱动电流调节（3.7A-7.8A有效值），适配42-86mm多种三相混合式步进电机
- 信号端口采用光电隔离设计，具备防过流保护，可直接接收3.3V-12V脉冲信号
- 脉冲输入频率最高可达1MHz，兼顾高细分与高速运行特性
- 内置过流、过压、过热、相间短路四重保护机制，保障设备安全运行
- 具备自动半流功能，无脉冲信号时自动减半电流，降低功耗与发热
- 支持断电相位保持功能，下次上电可精准维持电机原有位置
- 采用铝型材壳体散热设计，散热效率高，适应长时间高负载运行
- 兼容差分、共阳极、共阴极多种接口接法，接线灵活无需外接限流电阻
- 体积紧凑轻量化，仅为同类产品一半大小，便于狭小空间安装集成
- 支持调试软件参数整定与保存，搭配现场调试器可快速完成系统调试
- 电机仅需UVW三线连接，连线简单，安装调试便捷，适配自动化设备集成需求
810-801237-500步进驱动器模块 英文资料：
810-801237-500 Stepper Driver Module Product Features
-Adopting 32-bit DSP core control technology, stable driving performance, suitable for high-precision motion control scenarios
-Supports DC20-35V wide voltage input, compatible with various industrial power supplies, and has strong versatility
-Equipped with 16 levels of adjustable subdivision function, the highest subdivision can reach 60000 steps/turn, and the positioning accuracy is excellent
-Integrated enhanced subdivision technology can automatically smooth the motion trajectory and solve the problem of low-speed jitter in low subdivision
-Supports 4-speed drive current regulation (3.7A-7.8A effective value), compatible with various three-phase hybrid stepper motors ranging from 42-86mm
-The signal port adopts optoelectronic isolation design, with overcurrent protection, and can directly receive 3.3V-12V pulse signals
-Pulse input frequency can reach up to 1MHz, balancing high subdivision and high-speed operation characteristics
-Built in overcurrent, overvoltage, overheating, and phase to phase short circuit protection mechanisms ensure the safe operation of equipment
-Equipped with automatic half current function, it automatically halves the current when there is no pulse signal, reducing power consumption and heat generation
-Support power-off phase retention function, which can accurately maintain the original position of the motor when powered on next time
-Adopting aluminum shell heat dissipation design, high heat dissipation efficiency, suitable for long-term high load operation
-Compatible with differential, common anode, and common cathode interface connections, flexible wiring without the need for external current limiting resistors
-Compact and lightweight in size, only half the size of similar products, making it easy to install and integrate in small spaces
-Support debugging software parameter tuning and saving, coupled with on-site debugger to quickly complete system debugging
-The motor only requires UVW three wire connection, with simple wiring, easy installation and debugging, and is suitable for the integration needs of automation equipment
